Page #32 background imageLoading...
Page #32 background image
IDEC SmartRelay installation and wiring
2.2 Installing/removing IDEC SmartRelay
IDEC SmartRelay Manual
20
2.2 Installing/removing IDEC SmartRelay
Dimensions
The IDEC SmartRelay installation dimensions are compliant with DIN 43880.
IDEC SmartRelay can be snap-mounted to 35 mm DIN rails according to EN 60715 or
mounted on the wall with two M4 screws.
IDEC SmartRelay width:
Text Display has a width of 128.2 mm.
Base Modules have a width of 71.5 mm.
Expansion Modules have a width of 35.5mm (FL1F-M08...)
Note
The figures below show you an example of the installation and removal of an FL1F-
H12RCE and a digital module. The measures shown apply to all other Base Module
versions and expansion modules.
WARNING
Risk to life when you touch live parts
Death or serious injury can result when you touch live parts.
Always switch off power before you remove or insert an expansion module.
