Technical data
A.2 Technical data: FL1F-B12RCC/H12RCC
A.2 Technical data: FL1F-B12RCC/H12RCC
FL1F-B12RCC FL1F-H12RCC
Power supply
Input voltage 100 VAC/VDC to
240VAC/VDC
100 VAC/VDC to
240VAC/VDC
Permissible range 85VAC to 265VAC
100VDC to 253VDC
85VAC to 265VAC
100VDC to 253VDC
Permissible mains frequency 47Hz to 63 Hz 47Hz to 63 Hz
Power consumption
• 100 VAC
• 240 VAC
• 100 VDC
• 240 VDC
• 15mA to 40 mA
• 15mA to 25 mA
• 5mA to 10 mA
• 2mA to 8 mA
• 15mA to 40 mA
• 15mA to 25 mA
• 5mA to 10 mA
• 2mA to 8 mA
Voltage failure buffering
• 110 VAC/VDC
• 240 VAC/VDC
• Typ. 10 ms
• Typ. 20ms
• Typ. 10 ms
• Typ. 20ms
Power loss at
• 100 VAC
• 240 VAC
• 100 VDC
• 240 VDC
• 1.7W to 4.6 W
• 3.6W to 6.0 W
• 0.6W to 1.2 W
• 0.5W to 2.0 W
• 1.7W to 4.6 W
• 3.6W to 6.0 W
• 0.6W to 1.2 W
• 0.5W to 2.0 W
Backup of the real-time clock at 25 °C Typ. 20 days Typ. 20 days
Accuracy of the real-time clock Typ. ± 2 s/day Typ. ± 2 s/day
Digital inputs
Number 8 8
Electrical isolation No No
Number of high speed inputs 0 0
Input frequency
• Normal input
• High speed input
• Max. 4 Hz
• - -
• Max. 4 Hz
• - -
Max. continuous permissible voltage 265 VAC
253 VDC
265 VAC
253 VDC
Input voltage L1
• Signal 0
• Signal 1
• Signal 0
• Signal 1
• < 40 VAC
• > 79 VAC
• < 30 VDC
• > 79 VDC
• < 40 VAC
• > 79 VAC
• < 30 VDC
• > 79 VDC
Input current at
• Signal 0
• Signal 1
• Signal 0
• Signal 1
• < 0.05 mA AC
• > 0.08 mA AC
• < 0.06 mA DC
• > 0.13 mA DC
• < 0.05 mA AC
• > 0.08 mA AC
• < 0.06 mA DC
• > 0.13 mA DC
