Technical data
A.1 General technical data
IDEC SmartRelay Manual
284
Air pressure 795hPa to 1080 hPa
Pollutants IEC 60068-2-42
IEC 60068-2-43
SO
2
10cm
3
/m
3
, 21days
H
2
S 1cm
3
/m
3
, 21days
Ambient mechanical conditions
Degree of protection IP20 for IDEC SmartRelayBase
Modules, expansion modules,
and the FL1F-RD1 excluding
the TDE front panel
IP65 for FL1F-RD1 front panel
Vibrations: IEC 60068-2-6 5Hz to 8.4Hz
(constant amplitude 3.5 mm)
8.4Hz to 150 Hz
(constant acceleration 1 g)
Shock IEC 60068-2-27 18 shocks
(half-sine wave 15 g/11 ms)
Free fall (packaged) IEC 60068-2-32 0.3m
EMC specification
Noise emission EN 55011
EN 55022
Limit class B group 1
Limit class B
Electrostatic discharge IEC 61000-4-2
Severity 3
8 kV air discharge
6 kV contact discharge
Electromagnetic fields IEC 61000-4-3 Field strength 1 V/m and 10 V/m
HF currents on cables and cable
shielding
IEC 61000-4-6 10 V
Burst pulses IEC 61000-4-4Severity 3 2 kV (supply and digital signal
lines), 1kV (analog signal lines)
High-energy surge pulse (applies only
to FL1F-B12RCC/H12RCC)
IEC 61000-4-5Severity 3 1 kV (power lines) symmetrical
2 kV (power lines) asymmetrical
Safety to IEC
Clearance and creepage distance
rating
IEC 60664, IEC 61131-2,
EN 50178
UL 508
CSA C22.2 No. 142
Fulfilled
Insulation strength IEC 61131-2 Fulfilled
Cycle time
Cycle time per function < 0.1 ms
Startup
Startup time at power-up Typ. 9 s
FL1F communication
Delay time Max. 100ms
Criterion Tested in accordance with Values
