IDEC SmartRelay Manual
301
Technical data
A.12 Technical data: IDEC SmartRelay Power 24 V
A.12 Technical data: IDEC SmartRelay Power 24 V
IDEC SmartRelay Power 24 V is a primary.
A.13 Technical data: FL1F-RD1 (Text Display with Ethernet interfaces)
FL1F-RD1
Mechanical data
Keyboard
Display
Membrane keypad with 10 keys
FSTN-Graphic Display with 160 x 96 (columns x rows), LED
backlight (white/amber/red)
Power supply
Input voltage 24 VAC/VDC
12 VDC
Permissible range 20.4VAC to 26.4 VAC
10.2VDC to 28.8 VDC
Permissible mains frequency 47Hz to 63 Hz
Power consumption (Ethernet and
white backlight active)
• 12 VDC
• 24 VDC
• 24 VAC
• Typ. 145 mA
• Typ. 70 mA
• Typ. 75 mA
Degree of protection
IP20 for FL1F-RD1 excluding front panel
IP65 for FL1F-RD1 front panel
Communication port
Ethernet performance Two Ethernet interfaces with 10/100 M full/half duplex data
transmission rate
Connection distance Max. 30 m
LCD Display and Backlight
Backlight lifetime
1)
20,000 hours
Display lifetime
2)
50,000 hours
Mounting
Mounting hole dimensions (WxH) (119 + 0.5 mm) x (78.5 + 0.5 mm)
Mounting conditions Mount the FL1F-RD1 vertically on a flat surface of an IP 65
or Type 4x/12 enclosure.
1)
The backlight lifetime is when the final brightness is 50% of the original brightness.
2)
The display lifetime is calculated under ordinary operating and storage conditions: room temperature
(20 ± 8 °C), normal humidity below 65% relative humidity, and not in exposure to direct sunlight.
