IDEC SMARTRELAY User Manual

Technical data
A.2 Technical data: FL1F-B12RCC/H12RCC
IDEC SmartRelay Manual
286
Delay time at 0 to 1:
• 120 VAC
• 240 VAC
• 120 VDC
• 240 VDC
Delay time at 1 to 0:
• 120VAC
• 240VAC
• 120 VDC
• 240VDC
• Typ. 40 ms
• Typ. 30 ms
• Typ. 25 ms
• Typ. 20 ms
• Typ. 45 ms
• Typ. 70 ms
• Typ. 60 ms
• Typ. 75 ms
• Typ. 40 ms
• Typ. 30 ms
• Typ. 25 ms
• Typ. 20 ms
• Typ. 45 ms
• Typ. 70 ms
• Typ. 60 ms
• Typ. 75 ms
Line length (unshielded) max. 100 m max. 100 m
Digital outputs
Number 4 4
Output type Relay outputs Relay outputs
Electrical isolation Yes Yes
Dielectric Strength
(between power/input terminals and
output terminals)
2,500 V AC, 1minute
500 V DC, 1 minute
2,500 V AC, 1minute
500 V DC, 1 minute
In groups of 1 1
Control of a digital input Yes Yes
Continuous current I
th
Recommended range of
application ≥ 100mA at
12VAC/VDC
Max. 10 A per relay
Recommended range of
application ≥ 100mA at
12VAC/VDC
Max. 10 A per relay
Surge current
Incandescent lamp load
(25000 switching cycles) at
• 230/240 VAC
• 110/120 VAC
Max. 30 A
• 1000 W
• 500 W
Max. 30 A
• 1000 W
• 500 W
Fluorescent tubes with ballast
(25000 switching cycles)
10 x 58 W (at 230/240 VAC) 10 x 58 W (at 230/240 VAC)
Fluorescent tubes, conventionally
compensated
(25000 switching cycles)
1 x 58 W (at 230/240 VAC) 1 x 58 W (at 230/240 VAC)
Fluorescent tubes, uncompensated
(25000 switching cycles)
10 x 58 W (at 230/240 VAC) 10 x 58 W (at 230/240 VAC)
Short circuit-proof cos 1 Power protection B16, 600 A Power protection B16, 600 A
Short circuit-proof cos 0.5 to 0.7 Power protection B16, 900 A Power protection B16, 900 A
Derating None; across the entire
temperature range
None; across the entire
temperature range
Parallel output circuits for power
increase
Not permitted Not permitted
Protection of output relay
(if desired)
Max. 16 A, characteristic B16 Max. 16 A, characteristic B16
Initial Contact Resistance 100 mΩ maximum
(at 1A, 24V DC)
100 mΩ maximum
(at 1A, 24V DC)
Mechanical Life 10,000,000 operations
minimum (no load, 10 Hz)
10,000,000 operations
minimum (no load, 10 Hz)
FL1F-B12RCC FL1F-H12RCC
