Programming IDEC SmartRelay
3.9 Memory space and circuit program size
IDEC SmartRelay Manual
108
*: Bytes in the REM memory area if you have enabled retentivity
Utilization of memory areas
IDEC SmartRelay indicates that there is insufficient memory space by not allowing you to add
a block to your circuit program. IDEC SmartRelay offers you only the blocks for which it can
provide sufficient memory space. If IDEC SmartRelay memory space is insufficient to hold
any additional blocks, the system denies access to the block list.
If memory space is full, optimize your circuit program or install another IDEC SmartRelay.
Analog differential trigger 20 -
Analog comparator 24 -
Analog watchdog 24 -
Analog amplifier 12 -
Pulse Width Modulator (PWM) 32 -
Analog math 24 -
Analog math error detection 16 1
Analog multiplexer 20 -
Analog ramp control 40 -
PI controller 44 2
Analog filter 20 -
Max/Min 20 7
Average value 32 20
Others
Latching relay 12 1
Current impulse relay 12 1
Message texts 12 -
Softkey 12 2
Shift register 16 1
Note
Since a UDF block is a preconfigured circuit program that you create from WindLGC for your
IDEC SmartRelay device, the memory size (program memory and REM memory) of a UDF
block depends upon the size of the function blocks contained in the UDF.
Function
Program
memory
REM
memory*
