IDEC SmartRelay functions
4.4 Special functions list - SF
IDEC SmartRelay Manual
156
Parameter assignment screen form
View of the parameter assignment screen form, for example for Cam1 and the Pulse setting:
Days of the week
The prefix D (Day) has the following meaning:
M: Monday
T: Tuesday
: ednesday
T: Thursday
F: Friday
S: Saturday
S: Sunday
Uppercase letters indicate a specific day of the week. A - indicates no selection for the day
of the week. Each character is displayed in the order of the days of the week. Saturday and
Sunday are distinguished by its position.
On-/Off-times
Any time between 00:00 h and 23:59 h is possible. ou can also configure the on time to be a
pulse signal. The timer block will be activated at the specified time for one cycle and then the
output is reset.
- -:- - means: No on-/off-times set.
2IIWLPHK
2QWLPHK
:HHNGD\VGDLO\
