IDEC SMARTRELAY User Manual

IDEC SmartRelay functions
4.4 Special functions list - SF
IDEC SmartRelay Manual
198
Message text function block
Restriction
A maximum of 50 message text blocks are available.
Functional description
hen IDEC SmartRelay is in RUN mode, IDEC SmartRelay displays the message text that
you have configured along with its parameter values upon a 0 to 1 transition of the signal at
input En.
Based on your setting for the message destination, the message text displays on the IDEC
SmartRelayonboard display, the FL1F-RD1, or both.
If you use marker M27 in your circuit program, then if M270 (low) then IDEC SmartRelay
displays the message text only if it is from the primary character set (Character Set 1). If
M271 (high), then IDEC SmartRelay displays the message text only if it is from the
secondary character set (Character Set 2). (See the M27 marker description in topic
Constants and connectors (Page 111)).
If you have configured message ticking, the message will tick on and off the display according
to your specifications, either a character at a time, or a line at a time.
If acknowledgment is disabled (Ack  No), the message text is hidden when the status of the
signal at input En changes from 1 to 0.
Symbol in
IDEC SmartRelay
iring Description
Input En A 0 to 1 transition at input En (Enable) starts the
output of the message text.
Parameter Ack: acknowledgment of the message text
Msg Text: input of the message text
Priority: priority of the message text
Range of values: 0 to 127
Tick Type:
 C-C: tick message character by character
 L-L: tick message line by line
Msg. Dst: message destination (BM, TDE or Both)
eb Show: show IDEC SmartRelay Basic on eb
server
Line tick settings (to define whether a line ticks):
 Line1 Tick
 Line2 Tick
 Line3 Tick
 Line4 Tick
 Line5 Tick
 Line6 Tick
Note: ou can only edit the Text parameter of the
message from IDEC SmartRelay Basic. ISO8859-1 is
the only available character set for editing text. ou
can edit all other parameters, and other languages for
the Text parameter from indLGC. For configuration
details, refer to the Online Help for indLGC.
Output   remains set as long as the message text is set.
ಸಸ
ಸಸ
4
(Q
3DU
0HVVDJH7H[W
