IDEC SmartRelay functions
4.4 Special functions list - SF
Parameter Level 1 and Level 2:
levels to be reached
Range of values for each level:
-10000 to 20000
MaxL:
maximum value that must not be exceeded under any
circumstances.
Range of values: -10000 to 20000
StSp:
Start/Stop offset: value that is added to Offset "B" to
create the start/stop level. If the Start/Stop offset is 0,
then the start/stop level is Offset "B".
Range of values:
0 to 20000
Rate:
acceleration with which level 1, level 2 or Offset is
reached. Steps/seconds are issued.
Range of values:
1 to 10000
A: gain
Range of values:
0 to 10.00
B: offset
Range of values:
-10000 to 10000
p: number of decimals
Range of values:
0, 1, 2, 3
Output AQ Range of values for AQ:
0 to 32767
(Current Level - Offset "B") / Gain "A"
Range of values:
0 to 32767
Note:
When AQ is displayed in parameter mode or message
mode, it is displayed as a scaled value, both on the
IDEC SmartRelay Base Module and WindLGC
(engineering units: current level).
Symbol in
IDEC SmartRelay
Wiring Description
