Technical data
A.8 Technical data: FL1F-B12RCE/H12RCE, FL1F-M08B2R2
Notice: For fluorescent lamps with capacitors, you must consider the technical data of
fluorescent lamp ballasts. If the current exceeds the maximum allowed surge current,
appropriate contactor relays must switch the flourescent lamps.
Line length (shielded and twisted) Max. 10 m - -
Error limit ± 1.5% at FS - -
Digital outputs
Number 4 4
Output type Relay outputs Relay outputs
Electrical isolation Yes Yes
In groups of 1 1
Control of a digital input Yes Yes
Continuous current I
th (per terminal)
Recommended range of
application ≥ 100mA at 12VAC/
VDC
Max. 10A per relay
Recommended range of
application ≥ 100mA at
12VAC/VDC
Max. 5 A per relay
Surge current Max. 30 A Max. 30 A
Incandescent lamp load
(25000 switching cycles) at
1000W 1000W
Fluorescent tubes with ballast
(25000 switching cycles)
10 x 58 W 10 x 58 W
Fluorescent tubes, conventionally
compensated (25000 switching
cycles)
1 x 58 W 1 x 58 W
Fluorescent tubes, uncompensated
(25000 switching cycles)
10 x 58 W 10 x 58 W
Derating None; across the entire
temperature range
None; across the entire
temperature range
Short circuit-proof cos 1 Power protection B16, 600A Power protection B16, 600
A
Short circuit-proof cos 0.5 to 0.7 Power protection B16, 900A Power protection B16, 900
A
Parallel output circuits for power
increase
Not permitted Not permitted
Protection of output relay
(if desired)
Max. 16 A,
characteristic B16
Max. 16 A,
characteristic B16
Switching rate
Mechanical 10 Hz 10 Hz
Ohmic load/lamp load 2 Hz 2 Hz
Inductive load 0.5 Hz 0.5 Hz
FL1F-B12RCE
FL1F-H12RCE
FL1F-M08B2R2
