CA-6075 Class A Expander Installation
e Class A conguration requires the use of the CA-6075. Once the card is installed, the additional terminals are
provided for the return loop of the NAC. e CA-6075 provides the terminals for both NACs, SLCs, and P-Link.
Refer to the gures below for examples of installing and wiring a Class A expander card.
Notes:
1. One (1) CA-6075 Class A expander may be installed per panel.
2. e CA-6075 provides the terminals for NACs, P-Link, and SLCs.
Figure 30. Examples of Installing and Wiring a Class A Expander Card
CA-6075
Class A Expander
#6-32 x 7/8 screws
5050793 bracket
#6-32 x 1/4 screws
guide pins
DWG #593-27
DWG #602-5A
NAC 1 NAC 2
- + - +
Notification
Appliance
NAC 1 NAC 2
- + - +
CA-6075 Class A card
