Page: 35
JFS-A1 INSTALLATION, OPERATION, AND INSTRUCTION MANUAL
Document # : DOC230
Issued: August 27, 2012
Revised: N/A
Menu Navigation Keys
e arrow keys allow you to scroll or move through the control panel menus. e Enter and Esc keys may also
be used to navigate through menus; they are located on the numeric keypad. e table shown below provides a
summary of the navigation keys.
Table 6: Menu Navigation Keys
Push button Description
Moves/scrolls up or down through menus.
Scrolls to the left or right to display details, if any, of current menu item.
Note: When the LCD panel displays a LEFT and/or RIGHT arrow, this indicates more information may be viewed.
Displays the Main Menu or selects the current menu option.
Note: e blinking “” indicates the current menu option.
Returns to previous menu or backs up to previous screen.
Numeric Keypad
e numeric keypad allows you to enter user codes when required to access restricted functions. Alternatively, the
numbers may be used to quickly select menu options vs. using the arrow and Enter keys to select a function.
Figure 39. Control Panel Numeric Keypad
Function Pushbuttons
e four (4) function pushbuttons are used when system alarm / trouble conditions occur or to perform a re drill.
Figure 40. Control Panel Pushbuttons
