JFS-A1 INSTALLATION, OPERATION, AND INSTRUCTION MANUAL
Document #: DOC230
Issued: August 27, 2012
Revised: N/A
Section6:PSN-1000/PSN-1000(E)–Installing,Operating&Programming
e PSN-1000 and PSN-1000(E) power supply boards provide power and communication expansion capability to the
PFC-6000 series control panels. ey provide an electrically isolated P-Link repeater output that supports additional
power and communications distance.
BoardSpecications
Cabinet Descriptions
y Sixteen (16) gauge sheet steel with hinged, locked doors
y Enclosure dimensions
PSN-1000 – 16" x 17" x 3-7/8" (non-removable door)
PSN-1000(E) – 26" x 17.6" x 3.75" (removable door)
Visual Indicators
y LED indicators (Green & Amber)
EnvironmentalSpecications
y Mount indoors only.
y Temperature 32° to 120°F, humidity 93% non-condensing.
y Verify panel is properly grounded.
y Remove all electronic assemblies prior to any drilling, ling, reaming, or punching of the enclosure. When
possible, make all cable entries from the sides, bottom, or rear of the cabinet. Verify that they will not interfere
with the batteries or other components.
y e panel must be tested and maintained in accordance with all local and national codes and ordinances. Refer to
Appendix D: PSN-1000/PSN-1000(E) Maintenance and Testing for information on maintenance and testing
recommendations.
ElectricalSpecications
Please refer to the table below for the board's electrical specications:
Table 22: PSN-1000/PSN-1000(E)BoardElectricalSpecications
# NACs Rating per NAC Input Circuits Style and Class
6 3 Amp 1 Amp
Class A or B
NACs are Power Limited
Note: Refer to the "NACs Wiring" topic located in this section for
Class A wiring requirements.
WiringSpecications
ere are several wiring requirements to consider before connecting circuits to the PSN-1000/PSN-1000(E) board:
1) the circuit separation, and 2) the wiring types.
Circuit Separation
y Separations between the dierent wiring types must be maintained by at least ¼inch and the wire insulation
must be for the higher voltage.
y e two cabinets have various conduit knockouts located for ease of wire installation and allowing the installer
to maintain power limited and non-power limited connections.
