Janus JFS-A1 - NAC Functions

Page: 72
JFS-A1 INSTALLATION, OPERATION, AND INSTRUCTION MANUAL
Document #: DOC230
Issued: August 27, 2012
Revised: N/A
NAC Functions
e four (4) on-board circuits (NACs 1&2, I/O Ckts 1&2) are automatically congured as “General Purpose”,
but may be recongured and renamed. e I/O circuits have additional conguration options since they may be
congured as inputs. Refer to the two (2) tables below for descriptions of the conguration functions.
Table 18: NACandI/OCircuitCongurationFunctions
Function Description
Unused Circuit is unused.
General Purpose General purpose NAC; obeys zone “output pattern” programming.
Potter Sync Drives Potter synchronized horns / strobes.
Gentex Sync Drives Gentex synchronized horns / strobes.
System Sensor Sync Drives System Sensor synchronized horns / strobes.
Wheelock Sync Drives Wheelock synchronized horns / strobes.
Aux Constant Constant DC power.
Aux Resettable Constant DC power; disconnects power during system reset.
Aux Door Holder Constant DC power; disconnects when an alarm occurs.
Aux Door Holder Low AC Drop Constant DC power; disconnects on AC Loss or when an alarm occurs.
Aux ANSI Always on ANSI pattern used for ASB pattern synchronization.
City Tie Municipal box connection
Release Solenoid Solenoid output circuit
Table 19: I/OCircuitFunctions
Function Description
Input Pull Station Pull Station Input
Input Water Flow Water Flow Input obeys water ow delay as dened in “General Options”.
Input Supervisory Supervisory Input
Input Tamper Tamper Input reports as supervisory.
Input Fire Drill Fire Drill Input activates a re drill.
Input Trouble Monitor Trouble Input creates a trouble condition.
Input Aux Aux Input reports as un-typed alarm.
Input Abort Abort Input is used only with releasing applications.
Input Release Follower Release Follow Input causes immediate activation of release solenoid.
Input Reset Reset input initiates system reset.
Input Silence Silence Input initiates system silence.
Trigger IO Reverse Polarity Reverse Polarity Output report trouble.
Trigger IO Reverse Polarity No
Trouble
Reverse Polarity Output report no trouble.
