Program Icons
e panel software uses several standard Windows’ icons, such as the close button and scroll bars. ere are others
that are unique to the panel software, such as auto hide, and window position which are summarized in the table
below:
Table 11: PanelCongurationIcons
Name Icon Description/Function
Window Position
Located in the upper right region of some windows.
Click the icon to choose an option:
•y Floating – window oats over other windows; right-click title bar to reselect
dockable.
•y Dockable – default window position; window is “locked” in place.
•y Auto Hide – window is hidden when cursor is moved and “tab” displays
as window placeholder; point to window “tab” to redisplay (Window Tab
is explained below.)
Auto-Hide
Shortcut to hide a window.
•y Click to hide window.
•y Icon changes to (insert window autohide if window is hidden.
•y Click to unhide and dock window.
Window “Tab”
Displays if window is hidden; available for specic windows only.
Note: “Tab” name is specic to the hidden window.
•y Point to “Tab” to display window.
•y Point or click in another window to hide.
Example of Zone tab:
Expand / Collapse
Available in Zones and Points windows only.
•y Click the plus sign to expand.
•y Click the minus sign to collapse.
Example of expand/collapse icons in Points window:
Tab
