ReleasingZoneCongurations
e exibility of the JFS-A1 system provides the platform for a variety of releasing applications. is discussion
addresses several releasing conguration examples that may be used for water and chemical agent releasing zones:
• One Count or Single Interlock
• Cross Zone/Two Count (Double Interlock)
• Cross Zone/Two Count with Abort
Releasing Fields
When dening a Releasing zone, the following elds are integral to conguring the zone’s behavior.
Figure 102. Releasing Zone Fields
e table shown below explains the function of these elds.
Table 21: Releasing Zone Fields
Fields Description
Abort Type
Default = None
Denes the manual input type, typically a switch, which stops or delays the extinguishing
agent from being released.
The abort types are:
1. ULI (Underwriters Laboratories Inc.)
- If abort switch is pressed during the pre-discharge time and the time remaining is greater
than (>) 10 seconds, the timer will continue counting down to 10 seconds, and then
stops.
- If abort switch is pressed during pre-discharge timer and the time left is less than (<) 10
seconds, the timer will be set to 10 seconds and holds.
- As long as the abort switch is active, the timer will not count down.
- If the switch is released, the pre-discharge time will resume the countdown.
- Abort sequence can be repeated as many times as desired.
- Trouble is generated if the abort switch is pressed when there is no pre-discharge
occurring.
2. NYC (Not UL Listed)
- If abort switch is pressed during the pre-discharge time, then 90 seconds is added to the
remaining time. Since manual release time MAX is 30 seconds, and AUTO release time
MAX is 60 seconds, the resulting maximum value is 150 seconds.
- As long as the abort switch is active, the timer will hold at the new value.
- If the switch is released, the pre-discharge time will resume the countdown.
- NYC mode is a one-shot operation, cannot be used more than once.
- Trouble is generated if the abort switch is pressed when there is no pre-discharge
occurring.
