Chapter 6 — PID Application
Table 117. Redundant Drive — P10.2
Code Parameter Min. Max. Unit Default ID Note
P10.2.1

Redundant Drive Enable 0 2476 See Par ID 1346
P10.2.2

Drive ID 0 5 0 2278
P10.2.3

Redundant Run Time Enable 0 2477 See Par ID 1346
P10.2.4 Redundant Run Time Reset 2478 See Par ID 2125
P10.2.5

Redundant RunTime Limit 0.0 300000.0 h 0.0 2479
Real Time Clock
Table 118. Interval 1 — P11.1
Code Parameter Min. Max. Unit Default ID Note
P11.1.1

Interval 1 Setting 0 2487 0 = Weekly
1 = Daily
P11.1.2

Interval 1 On Time 0 491
P11.1.3

Interval 1 Off Time 0 493
P11.1.4

Interval 1 From Day 0 517 0 = Sunday
1 = Monday
2 = Tuesday
3 = Wednesday
4 = Thursday
5 = Friday
6 = Saturday
P11.1.5

Interval 1 To Day 0 518 See Par ID 517
P11.1.6

Interval 1 Channel 0 519 0 = Not Used
1 = Time Channel 1
2 = Time Channel 2
3 = Time Channel 3
Table 119. Interval 2 — P11.2
Code Parameter Min. Max. Unit Default ID Note
P11.2.1

Interval 2 Setting 0 2488 See Par ID 2487
P11.2.2

Interval 2 On Time 0 495
P11.2.3

Interval 2 Off Time 0 497
P11.2.4

Interval 2 From Day 0 520 See Par ID 517
P11.2.5

Interval 2 To Day 0 521 See Par ID 517
P11.2.6

Interval 2 Channel 0 522 See Par ID 519
Table 120. Interval 3 — P11.3
Code Parameter Min. Max. Unit Default ID Note
P11.3.1

Interval 3 Setting 0 2489 See Par ID 2487
P11.3.2

Interval 3 On Time 0 499
P11.3.3

Interval 3 Off Time 0 501
P11.3.4

Interval 3 From Day 0 523 See Par ID 517
P11.3.5

Interval 3 To Day 0 524 See Par ID 517
P11.3.6

Interval 3 Channel 0 525 See Par ID 519
ote: N

Parameter value can only be changed after the drive has stopped.

Parameter value will be set to be default when changing macros.
