Johnson Controls VS3 Series User Manual

90 VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Chapter 6 — PID Application
Code Parameter Min. Max. Unit Default ID Note
P13.1.20

Output Display Unit 45 2424 0 = %
1 = 1/min
2 = rpm
3 = ppm
4 = pps
5 = l/s
6 = l/min
7 = l/h
8 = kg/s
9 = kg/min
10 = kg/h
11 = m3/s
12 = m3/min
13 = m3/h
14 = m/s
15 = mbar
16 = bar
17 = Pa
18 = kPa
19 = mVS
20 = kW
21 = ˚C
22 = GPM
23 = gal/s
24 = gal/min
25 = gal/h
26 = lb/s
27 = lb/min
28 = lb/h
29 = CFM
30 = ft3/s
31 = ft3/min
32 = ft3/h
33 = ft/s
34 = in wg
35 = ft wg
36 = PSI
37 = lb/in2
38 = HP
39 = ˚F
40 = PA
41 = WC
42 = HG
43 = ft
44 = m
45 = Hz
46 = strokes/min
P13.1.21

Output Display Unit Min -60000.00 See Par ID 2425 Varies 0.00 2460
P13.1.22

Output Display Unit Max See Par ID 2460 60000.00 Varies Varies 2425
Table 133. Version Info — P13.2
Code Parameter Min. Max. Unit Default ID Note
P13.2.1 Keypad Software Version 640
P13.2.2 Motor Control Software Version 642
P13.2.3 Application Software Version 644
P13.2.4 Software Bundle Version 1714
ote: N

Parameter value will be set to be default when changing macros.
Table 132. Basic Setting — P13.1, continued
