Chapter 5—Basic application
VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Table 20. Optional Boards — M3
Code Parameter Min. Max. Unit Default ID Note
M3.1 PT100 Temperture C 1000.0 27
Table 21. Energy Savings — M4
Code Parameter Min. Max. Unit Default ID Note
M4.1

Energy Savings Varies 0.000 2120
Table 22. FB Monitor Menu — M5
Code Parameter Min. Max. Unit Default ID Note
M5.1 Control Board DIDO Status 2209 Bit 0 = DIN1 Status
Bit 1 = DIN2 Status
Bit 2 = DIN3 Status
Bit 3 = DIN4 Status
Bit 4 = DIN5 Status
Bit 5 = DIN6 Status
Bit 6 = DIN7 Status
Bit 7 = DIN8 Status
Bit 8 = DO1 Status
Bit 9 = RO1 Status
Bit 10 = RO2 Status
Bit 11 = RO3 Status
Bit 12 = SlotA with board
Bit 13 = SlotB with board
Bit 14 = Virtual RO1 Status
Bit 15 = Virtual RO2 Status
M5.2 SlotA DIDO Status 2210 Bit 0 = IO1_DIN1 Status
Bit 1 = IO1_DIN2 Status
Bit 2 = IO1_DIN3 Status
Bit 3 = IO1_DO1 Status
Bit 4 = IO1_DO2 Status
Bit 5 = IO1_DO3 Status
Bit 6 = IO3_RO1 Status
Bit 7 = IO3_RO2 Status
Bit 8 = IO3_RO3 Status
Bit 9 = IO5_AC1 Status
Bit 10 = IO5_AC2 Status
Bit 11 = IO5_AC3 Status
Bit 12 = IO5_AC4 Status
Bit 13 = IO5_AC5 Status
Bit 14 = IO5_AC6 Status
M5.3 SlotB DIDO Status 2211 Bit 0 = IO1_DI1
Bit 1 = IO1_DI2
Bit 2 = IO1_DI3
Bit 3 = IO1_DO1
Bit 4 = IO1_DO2
Bit 5 = IO1_DO3
Bit 6 = IO3_RO1
Bit 7 = IO3_RO2
Bit 8 = IO3_RO3
Bit 9 = IO5_AC1
Bit 10 = IO5_AC2
Bit 11 = IO5_AC3
Bit 12 = IO5_AC4
Bit 13 = IO5_AC5
Bit 14 = IO5_AC6
Bit 15 = Not Used
Note:

Parameter value will be set to be default when changing macros.
