28 VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Chapter 4—Startup
Item Description
17 Hand Reference, continued 13 = AI1 * AI2
14 = AI1 or AI2
15 = Min(AI1,AI2)
16 = Max(AI1,AI2)
17 = PID1 Control Output
18 = PID2 Control Output
18 Auto 1 Control Place 0 = I/O terminal Start 1
1 = Fieldbus
2 = I/O terminal start 2
3 = Keypad
19 Auto 1 Reference 0 = AI1
1 = AI2
2 = Slot A: AI1
3 = Slot B: AI1
4 = AI1 Joystick
5 = AI2 Joystick
6 = Keypad
7 = Feildbus
9 = Max Frequency
10 = AI1 + AI2
11 = AI1 - AI2
12 = AI2 - AI1
13 = AI1 * AI2
14 = AI1 or AI2
15 = Min(AI1,AI2)
16 = Max(AI1,AI2)
17 = PID1 Control Output
18 = PID2 Control Output
20 Bypass Enabled 0 = Disabled
1 = Enabled
21 Application Mini-Wizard Press OK?
Now the Startup Wizard is done. It will not show again at
the next power up. If you want to reset it, please select it
from the main menu (“Startup Wizard”).
PID and Advanced Application Mini-Wizard
The PID Mini-Wizard is activated in the Quick Setup menu.
This Wizard assumes that you are going to use the PID
controller in the “one feedback/one setpoint” mode. The
control place will be I/O A and the default process unit “%”.
The PID Mini-Wizard asks for the following values to be set:
Table 15. PID Mini-Wizard values
Item Description
20 PID 1 Process Unit Select Units
21 PID1 Process Unit Min Min: –99999.99
Max: PID1 Process Unit Max
22 PID1 Process Unit Max Min: PID1 Process Unit Min
Max: 99999.99
23 PID 1 Set Point 1 Source Select Function
24 PID 1 Keypad Set Point 1 Min: PID 1 Process Unit Min
Max: PID 1 Process Unit Max
25 PID 1 Feedback 1 Source Select Input
26 PID 1 Feedback 1 Min Min: –200%
Max: 200%
27 PID 1 Feedback 1 Max Min: –200%
Max: 200%
Table 14. Startup wizard instructions continued
