Chapter 5—Basic application
VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Table 44. Auto Restart — P6.4
Code Parameter Min. Max. Unit Default ID Note
P6.4.1
AR Wait Time 1.00 300.00 s 1.00 321
P6.4.2
AR Trail Time 0.00 600.00 s 30.00 322
P6.4.3
AR Start Function 0 323 0 = Flying Start
1 = Ramp
P6.4.4
Undervoltage Attempts 0 10 1 324
P6.4.5
OverVoltage Attempts 0 10 1 325
P6.4.6
OverCurrent Attempts 0 3 1 326
P6.4.7
4mA Fault Attempts 0 10 1 327
P6.4.8
Motor Temp Fault Attempts 0 10 1 329
P6.4.9
External Fault Attempts 0 10 0 328
P6.4.10
Underload Attempts 0 10 1 336
Table 45. Fire Mode — P9
Code Parameter Min. Max. Unit Default ID Note
P9.1
Fire Mode Function 0 535 0 = Closing Contact
1 = Opening Contact
P9.2
Fire Mode Ref Select
Function
0 536 0 = Fire Mode Min Frequency
1 = Fire Mode Ref
2 = Fieldbus Ref
3 = AI1
4 = AI2
5 = AI1 + AI2
P9.3
Fire Mode Min Frequency See Par ID 101 See Par ID 102 Hz 15.00 537
P9.4
Fire Mode Freq Ref 1 0.0 100.0 % 75.0 565
P9.5
Fire Mode Freq Ref 2 0.0 100.0 % 100.0 564
P9.6 Fire Mode Test Enable 2443 See Par ID 1679
Bypass
Table 46. Basic Setting — P10.1
Code Parameter Min. Max. Unit Default ID Note
P10.1.1
Bypass Enable 1 1418 See Par ID 1679
P10.1.2
Bypass Start Delay 1 32765 s 1 544
P10.1.3
Auto Bypass 1 542 See Par ID 1679
P10.1.4
Auto Bypass Delay 0 32765 s 10 543
P10.1.5
OverCurrent Bypass Enable 1 547 See Par ID 1679
P10.1.6
IGBT Fault Bypas Enable 1 546 See Par ID 1679
P10.1.7
4mA Fault Bypass Enable 1 548 See Par ID 1679
P10.1.8
UnderVoltage Bypass Enable 1 545 See Par ID 1679
P10.1.9
OverVoltage Bypass Enable 1 549 See Par ID 1679
P10.1.10
Motor OverTemp Bypass Enable 1 1698 See Par ID 1679
P10.1.11
UnderLoad Bypass Enable 1 1699 See Par ID 1679
P10.1.12
External Bypass Enable 1 1700 See Par ID 1679
P10.1.13
Charge Switch Fault Bypass Enable 1 1701 See Par ID 1679
P10.1.14
Saturation Trip Fault Bypass Enable 1 1702 See Par ID 1679
P10.1.15
Under Temp Fault Bypass Enable 1 1703 See Par ID 1679
P10.1.16
EEPROM Fault Bypass Enable 1 1704 See Par ID 1679
P10.1.17
FRAM Fault Bypass Enable 1 1705 See Par ID 1679
P10.1.18
Watchdog Fault Bypass Enable 1 1706 See Par ID 1679
otes: N
Parameter value can only be changed after the drive has stopped.
Parameter value will be set to be default when changing macros.
