Johnson Controls VS3 Series User Manual

26 VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Chapter 3—Menu overview
1. If password is in use, password shall be needed to
check before edit parameter value.
2. If no action in 1min, the password shall need to be
checked again.
3. If Parameter locked is enabled, *Locked* shall be shown
if user tries to edit the parameter.
Figure 28. Parameter locked
REVERSE MENU13:53
STP FWD KEY PAR
P2.4.1- AI1 Mode
P2.4.2
P2.4.3
AI1 Custom min
Right/OK key
Locked
FAVORITE 13:53
STP FWD KEY PAR
P2.4.2
0
100%
AI1 Signal Range
Right key
13:53
STP FWD KEY PAR
P2.4.2
*Locked*
AI1 Signal Range
FAVORITE
MENU
MENU
After
AI1 Signal Range
T—Favorite
Favorites collect the user’s favorite parameters. User can
add one parameter into favorite list by “FAVORITE” soft key,
and can delete it from favorite list by “DELETE” soft key.
If a parameter has not been added into the favorite list, the
soft keys “FAVORITE” will be shown in parameter page (see
Figure 12 on Page 12). If it has been added into the favorite
list, the soft key “FAVORITE” will not be shown.
If a parameter has been added to the favorite list, it shall
appear in the favorite menu. Then when you enter into the
favorite menu, the soft keys “DELETE” will be shown. This
allows you to remove the selected parameter from favorite
list (see Figure 12 on Page 12).
After one parameter is removed from favorite list, the next
parameter in the favorite list will be selected by default.
