Johnson Controls VS3 Series User Manual

20 VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Chapter 3—Menu overview
Fault Log
The Fault Log will store the last 50 faults in it with 1 being
the most recent and 50 being the oldest. Only the fault
code, name and time stamp are stored with these faults.
P — Parameter
The navigation for the parameter menu is shown
in
Figure 21.
In parameter page, the parameter code shall be shown in
the second line (such as P1.1).
In parameter page, the parameter name shall be shown in
the third line (such as Min Frequency).
In parameter page, the value of parameter and unit shall be
shown in the fourth line (0.00 Hz).
If the parameter is read and write, then pressing the right
key shall make the parameter value flash, which means that
the value can be edited.
If the parameter is read only, then pressing the right
key will not have any effect, which means that the value
can’t be edited.
There are several special pages:
1. P 13.1.3 Parameter Sets. See Figure 22.
User shall be able to load or store parameters. The options
are as follows: Reload Defaults, Reload Set 1, Reload Set
2, Store Set 1, Store Set 2, Reset, Reload Defaults VM. The
special points are:
•
During this operation, “waiting…” shall flash, which
means it is in process
•
When it is finished, “OK” shall be shown
•
Drive shall restart after default parameters are loaded
•
“Reload Defaults VM” is for the sales stand. Do not use
on a fully functioning drive
Right/OK key
BYPASS REVERSE13:53
STP FWD KEY PAR
P1: Basic Parameters
P2: Input
13:53
STP FWD KEY PAR
P1.16 - Auto 2 Reference
P1.1:Min Frequency
P1.2: Max Frequency
BYPASS 13:53
STP FWD KEY PAR
P1.1
0.00 Hz
Min Frequency
Up key
Right key to
edit by digital
BYPASS JOG13:53
STP FWD KEY TPM
P: Parameter
F: Fault
P13: System
Right/OK
key
Right key
two times
13:53
STP FWD KEY PAR
13:53
STP FWD KEY PAR
13:53
STP FWD KEY PAR
Ok key
M: Monitor
P1.1
0.01 Hz
Min Frequency
P1.1
0.01 Hz
Min Frequency
P1.1
0.00 Hz
Min Frequency
Left key to
move the
edit bit
13:53
STP FWD KEY PAR
P1.1
0.00 Hz
Min Frequency
Up/down key to
edit during 0 - 9
13:53
STP FWD KEY PAR
13:53
STP FWD KEY PAR
Ok key to
confirm
P1.1
0.10 Hz
Min Frequency
P1.1
0.10 Hz
Min Frequency
BYPASS REVERSE
FAVORITE
BYPASSBYPASS
BYPASS
BYPASS
BYPASS
BYPASS
FAVORITE
FAVORITE
FAVORITEFAVORITE
FAVORITE
FAVORITE
Figure 22. Parameter setting
