Chapter 6 — PID Application
Table 76. Preset Speed — P2.3
Code Parameter Min. Max. Unit Default ID Note
P2.3.1
Preset Speed 1 0.00 See Par ID 102 Hz 5.00 105
P2.3.2
Preset Speed 2 0.00 See Par ID 102 Hz 10.00 106
P2.3.3
Preset Speed 3 0.00 See Par ID 102 Hz 15.00 118
P2.3.4
Preset Speed 4 0.00 See Par ID 102 Hz 20.00 119
P2.3.5
Preset Speed 5 0.00 See Par ID 102 Hz 25.00 120
P2.3.6
Preset Speed 6 0.00 See Par ID 102 Hz 30.00 121
P2.3.7
Preset Speed 7 0.00 See Par ID 102 Hz 35.00 122
P2.3.8
Jog Reference See Par ID 101 See Par ID 102 Hz 0.00 117
Table 77. AI1 Settings — P2.4
Code Parameter Min. Max. Unit Default ID Note
P2.4.1 AI1 Mode 1 222 0 = 0 - 20 mA
1 = 0 -10 V
P2.4.2
AI1 Signal Range 0 175 0 = 0-100%/0-20mA/0-10V
1 = 20-100%/4-20mA/2-10V
2 = Customized
P2.4.3
AI1 Custom Min 0.00 See Par ID 177 % 0.00 176
P2.4.4
AI1 Custom Max See Par ID 176 100.00 % 100.00 177
P2.4.5
AI1 Filter Time 0.00 10.00 s 0.10 174
P2.4.6
AI1 Signal Invert 0 181 0 = Not Inverted
1 = Inverted
Table 78. AI2 Settings — P2.5
Code Parameter Min. Max. Unit Default ID Note
P2.5.1 AI2 Mode 0 223 0 = 0 - 20 mA
1 = 0 -10 V
2 = -10 - +10 V
P2.5.2
AI2 Signal Range 1 183 0 = 0-100%/0-20mA/0-10V/-10-10V
1 = 20-100%/4-20mA/2-10V/-6-10V
2 = Customized
P2.5.3
AI2 Custom Min 0.00 See Par ID 185 % 0.00 184
P2.5.4
AI2 Custom Max See Par ID 184 100.00 % 100.00 185
P2.5.5
AI2 Filter Time 0.00 10.00 s 0.10 182
P2.5.6
AI2 Signal Invert 0 189 See Par ID 181
ote: N
Parameter value can only be changed after the drive has stopped.
Parameter value will be set to be default when changing macros.
Input function is level sensed.
