Chapter 7—Advanced application parameter
System
Table 210. Basic Setting — P13.1
Code Parameter Min. Max. Unit Default ID Note
P13.1.1 Language 0 340 0 = English
1 = ₼㠖
2 = Deutsch
P13.1.2

Application 142 0 = Basic
1 = PID
2 = Advanced
P13.1.3

Parameter Sets 619 0 = No
1 = Reload Defaults
2 = Reload Set 1
3 = Reload Set 2
4 = Store Set 1
5 = Store Set 2
6 = Reset
7 = Reload Defaults VM
P13.1.4 Up To Keypad 620 See Par ID 2118
P13.1.5

Down From Keypad 621 0 = No
1 = All Parameters
2 = All, No Motor
3 = App Parameters
P13.1.6 Parameter Comparison 623 0 = No
1 = Compare with Keypad
2 = Compare with Default
3 = Compare with Set 1
4 = Compare with Set 2
P13.1.7 Password 0 9999 0 624
P13.1.8 Parameter Lock 0 625 0 = Change Enable
1 = Change Disable
P13.1.9 Multimonitor Set 0 627 See Par ID 625
P13.1.10 Default Page 0 628 0 = None
1 = Main Menu
2 = Multi-Monitor
3 = Favorite Menu
4 = Keypad Reference
P13.1.11 Timeout Time 0 65535 s 30 629
P13.1.12 Contrast Adjust 5 18 12 630
P13.1.13 Backlight Time 1 65535 min 10 631
P13.1.14 Fan Control 2 632 0 = Continuous
1 = Temperature
2 = Run Follow
3 = Calculate IGBT Temp
P13.1.15 Keypad ACK Timeout 200 5000 ms 200 633
P13.1.16 Keypad Retry Number 1 10 5 634
P13.1.17 Startup Wizard 0 626 0 = Yes
1 = No
P13.1.18

Jog Softkey Hidden 0 2412 See Par ID 1346
P13.1.19

Reverse Softkey Hidden 0 2413 See Par ID 1346
Note:

Parameter value can only be changed after the drive has stopped.

Parameter value will be set to be default when changing macros.
