61VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com

Chapter 6 — PID Application

Table 69. Timer/Interval Control — M7

Code Parameter Min. Max. Unit Default ID Note

M7.1 TC1, TC2, TC3 558

M7.2 Interval 1 559 0 = Inactive

1 = Active

M7.3 Interval 2 560 See Par ID 559

M7.4 Interval 3 561 See Par ID 559

M7.5 Interval 4 562 See Par ID 559

M7.6 Interval 5 563 See Par ID 559

M7.7 Timer 1 s 0 569

M7.8 Timer 2 s 0 571

M7.9 Timer 3 s 0 573

Table 70. User Defined Output — M8

Code Parameter Min. Max. Unit Default ID Note

M8.1 Output Varies 2445

M8.2 Reference Varies 2447

Table 71. MWH Monitor — M9

Code Parameter Min. Max. Unit Default ID Note

M9.1 Total MWh Count Mwh 601

M9.2 Total Power Day Count 603

M9.3 Total Power Hr Count 606

M9.4 Trip MWh Count Mwh 604

M9.5 Trip Power Day Count 636

M9.6 Trip Power Hr Count 637

Table 72. Multi-Monitoring — M10

Code Parameter Min. Max. Unit Default ID Note

M10.1 Multi-Monitoring 1,2,3 30
