63VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Chapter 6 — PID Application
Table 75. Digital Input — P2.2
Code Parameter Min. Max. Unit Default ID Note
P2.2.1
IO Terminal 1 Start Stop
Logic
0 143 0 = Forward - Reverse
0 = Forward - Reverse
1 = Start - Reverse
2 = Start - Enable
3 = Start Pulse - Stop Pulse
P2.2.2
190 0 = DigIN:NormallyOpen
1 = DigIN:NormallyClose
2 = DigIN: 1
3 = DigIN: 2
4 = DigIN: 3
5 = DigIN: 4
6 = DigIN: 5
7 = DigIN: 6
8 = DigIN: 7
9 = DigIN: 8
10 = DigIN: A: IO1: 1
11 = DigIN: A: IO1: 2
12 = DigIN: A: IO1: 3
13 = DigIN: A: IO5: 1
14 = DigIN: A: IO5: 2
15 = DigIN: A: IO5: 3
16 = DigIN: A: IO5: 4
17 = DigIN: A: IO5: 5
18 = DigIN: A: IO5: 6
19 = DigIN: B: IO1: 1
20 = DigIN: B: IO1: 2
21 = DigIN: B: IO1: 3
22 = DigIN: B: IO5: 1
23 = DigIN: B: IO5: 2
24 = DigIN: B: IO5: 3
25 = DigIN: B: IO5: 4
26 = DigIN: B: IO5: 5
27 = DigIN: B: IO5: 6
28 = Time Channel 1
29 = Time Channel 2
30 = Time Channel 3
31 = RO1 Function
32 = RO2 Function
33 = RO3 Function
34 = Virtual RO1 Function
35 = Virtual RO2 Function
P2.2.3
191 See Par ID 190
P2.2.4
2206 See Par ID 143
P2.2.5
2207 See Par ID 190
P2.2.6
2208 See Par ID 190
P2.2.7
881 0 = Digital Input
1 = Thermistor Input
P2.2.8
198 See Par ID 190
P2.2.9
192 See Par ID 190
P2.2.10
193 See Par ID 190
P2.2.11
2297 0 = External Fault
1 = Vibration Cut out
2 = High Motor temp
3 = Low Pressure
4 = High Pressure
5 = Low Water
6 = Damper Interlock
7 = Run Enable
8 = Freeeze Stat Trip
9 = Smoke Detect
10 = Seal Leakage
11 = Rod Breakage
ote: N
Parameter value can only be changed after the drive has stopped.
Parameter value will be set to be default when changing macros.
Input function is level sensed.
Input function is edge sensed when using StartP/StopP start logic.
