87VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Chapter 6 — PID Application
Table 128. BACnet MS/TP — P12.3.3
Code Parameter Min. Max. Unit Default ID Note
P12.3.3.1
MSTP Baud Rate 2 594 0 = 9600
1 = 19200
2 = 38400
3 = 76800
4 = 115200
P12.3.3.2
MSTP Device Address 0 127 1 595
P12.3.3.3
MSTP Instance Number 0 4194302 Varies 596
P12.3.3.4 MSTP Comm Timeout 0 60000 ms 10000 598
P12.3.3.5 MSTP Protocol Status 599 0 = Stopped
1 = Operational
2 = Faulted
P12.3.3.6 MSTP Fault Code 600 0 = None
1 = Sole Master
P12.3.3.7
MSTP Fault Response 0 2526 See Par ID 2516
P12.3.3.8
MSTP Max Master 127 1537
EtherNet Bus
Table 129. Basic Setting — P12.4.1
Code Parameter Min. Max. Unit Default ID Note
P12.4.1.1
IP Address Mode 1 1500 0 = Static IP
1 = DHCP with AutoIP
P12.4.1.2 Active IP Address 1507
P12.4.1.3 Active Subnet Mask 1509
P12.4.1.4 Active Default Gateway 1511
P12.4.1.5 MAC Address 1513
P12.4.1.6
Static IP Address 192.168.1.254 1501
P12.4.1.7
Static Subnet Mask 255.255.255.0 1503
P12.4.1.8
Static Default Gateway 192.168.1.1 1505
P12.4.1.9
Enable BACnetIP 0 1725 See Par ID 1346
Table 130. Modbus TCP — P12.4.2
Code Parameter Min. Max. Unit Default ID Note
P12.4.2.1 Connection Limit 5 609
P12.4.2.2 Modbus TCP Unit ID 1 610
P12.4.2.3 Comm Timeout Modbus TCP 0 60000 ms 10000 611
P12.4.2.4 Modbus TCP Protocol Status 612 See Par ID 599
P12.4.2.5 Modbus TCP Fault Response 0 2517 See Par ID 2516
ote: N
Parameter value can only be changed after the drive has stopped.
Parameter value will be set to be default when changing macros.
