86 VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Chapter 6 — PID Application
Code Parameter Min. Max. Unit Default ID Note
P12.2.10
Standard Status Word Bit1
Function Select
22416See Par ID 2415
P12.2.11
Standard Status Word Bit2
Function Select
32417See Par ID 2415
P12.2.12
Standard Status Word Bit3
Function Select
42418See Par ID 2415
P12.2.13
Standard Status Word Bit4
Function Select
52419See Par ID 2415
P12.2.14
Standard Status Word Bit5
Function Select
62420See Par ID 2415
P12.2.15
Standard Status Word Bit6
Function Select
72421See Par ID 2415
P12.2.16
Standard Status Word Bit7
Function Select
82422See Par ID 2415
RS485 Bus
Table 126. Basic Setting — P12.3.1
Code Parameter Min. Max. Unit Default ID Note
P12.3.1.1
RS485 Comm Set 0 586 0 = Modbus RTU
1 = BACnet MS/TP
2 = SA Bus
Table 127. Modbus RTU — P12.3.2
Code Parameter Min. Max. Unit Default ID Note
P12.3.2.1
Slave Address 1 247 1 587
P12.3.2.2
Baud Rate 1 584 0 = 9600
1 = 19200
2 = 38400
3 = 57600
4 = 115200
P12.3.2.3
Parity Type 2 585 0 = None
1 = Odd
2 = Even
P12.3.2.4 Modbus RTU Protocol Status 588 0 = Initial
1 = Stopped
2 = Operational
3 = Faulted
P12.3.2.5 Comm Timeout Modbus RTU 0 60000 ms 10000 593
P12.3.2.6 Modbus RTU Fault Response 0 2516 0 = in Fieldbus Control
1 = in all Control
Table 125. FB Process Data Output Sel — P12.2, continued
ote: N
Parameter value can only be changed after the drive has stopped.
Parameter value will be set to be default when changing macros.
