Johnson Controls VS3 Series User Manual

53
Chapter 5—Basic application
VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Table 57. Version Info — P13.2
Code Parameter Min. Max. Unit Default ID Note
P13.2.1 Keypad Software Version 640
P13.2.2 Motor Control Software Version 642
P13.2.3 Application Software Version 644
P13.2.4 Software Bundle Version 1714
Table 58. Application Info — P13.3
Code Parameter Min. Max. Unit Default ID Note
P13.3.1 Brake Chopper 646 See Par ID 2118
P13.3.2 Brake Resistor Status 647 See Par ID 2118
P13.3.3 Serial Number 648
Table 59. User Info — P13.4
Code Parameter Min. Max. Unit Default ID Note
P13.4.1 Real Time Clock 0.0.0.1:1:13 566
P13.4.2 Daylight Saving 0 582
0 = Off
1 = EU
2 = US
P13.4.3 Total MWh Count Mwh 601
P13.4.4 Total Power Day Count 603
P13.4.5 Total Power Hr Count 606
P13.4.6 Trip MWh Count Mwh 604
P13.4.7 Clear Trip MWh Count 635 See Par ID 2125
P13.4.8 Trip Power Day Count 636
P13.4.9 Trip Power Hr Count 637
P13.4.10 Clear Trip Power Count 639 See Par ID 2125
Table 60. Operate Mode — O
Code Parameter Min. Max. Unit Default ID Note
O1 Output Frequency Hz 1
O2 Freq Reference Hz 24
O3 Motor Speed rpm 2
O4 Motor Current A 3
O5 Motor Torque % 4
O6 Motor Power % 5
O7 Motor Voltage V 6
O8 DC-link Voltage V 7
O9 Unit Temperature  8
O10 Motor Temperature % 9
R11

Keypad Reference See Par ID 101 See Par ID 102 Hz 0.00 141
otes: N

Parameter value can only be changed after the drive has stopped.

Parameter value will be set to be default when changing macros.
