126 VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Chapter 7—Advanced application parameter
Table 208. Modbus TCP — P12.4.2
Code Parameter Min. Max. Unit Default ID Note
P12.4.2.1 Connection Limit 5 609
P12.4.2.2 Modbus TCP Unit ID 1 610
P12.4.2.3 Comm Timeout Modbus TCP 0 60000 ms 10000 611
P12.4.2.4 Modbus TCP Protocol Status 612 See Par ID 599
P12.4.2.5 Modbus TCP Fault Response 0 2517 See Par ID 2516
Table 209. BACnet IP — P12.4.3
Code Parameter Min. Max. Unit Default ID Note
P12.4.3.1

BACnet IP UDP port number 47808 1733 47808 = BAC0
47809 = BAC1
47810 = BAC2
47811 = BAC3
47812 = BAC4
47813 = BAC5
47814 = BAC6
47815 = BAC7
47816 = BAC8
47817 = BAC9
47818 = BACA
47819 = BACB
47820 = BACC
47821 = BACD
47822 = BACE
47823 = BACF
P12.4.3.2

BACnet IP Foreign Device 0 1734 See Par ID 1346
P12.4.3.3

BACnet IP BBMD IP 0.0.0.0 1735
P12.4.3.4

BACnet IP BBMD Port 47808 1737 See Par ID 1733
P12.4.3.5

BACnet IP Registration
Interval
065535 10 1738
P12.4.3.6

BACnet IP Comm Timeout 0 60000 0 1739
P12.4.3.7 BACnet IP Protocol Status 1740 See Par ID 599
P12.4.3.8

BACnet IP Fault Behavior 0 1741 See Par ID 2516
P12.4.3.9

BACnetIP Instance Number 0 4194302 Varies 1742
Note:

Parameter value can only be changed after the drive has stopped.

Parameter value will be set to be default when changing macros.
