Chapter 2—Keypad overview
Upgrade page
After welcome page, keypad will check whether there is
different keypad firmware version in MCU’s serial flash. If
yes, then ask user whether to upgrade the keypad.
Figure 9. Upgrade page
13:53
STP FWD KEY QSW
Current Version: 1.01.0003
To Upgrade Version: 1.01.0004
To Upgrade? Press OK or BACK
Auto backup page
If keypad is plugged into a new drive, then auto backup
page will be shown to notice the user whether to do the
upload/download.
Figure 10. Auto backup page
13:53
STP FWD KEY MON
Download from keypad
No Action
Upload to keypad
Soft key description
There are two soft key buttons. They have different
definitions under different pages.
Table 12. Soft keys
Bypass Enabled
Keypad Display Softkey 1 Softkey 2
Main menu page Bypass Jog
Group node page
Bypass REVERSE/FORWARD
Parameter node page
Bypass Null/Favorite
favorite page
Bypass Delete
fault page
Bypass
REVERSE/FORWARD
Monitor Page
Bypass
REVERSE/FORWARD
Bypass Disabled
Keypad Display Softkey 1 Softkey 2
Main menu page
Null Jog
Group node page REVERSE/FORWARD Menu
Parameter node page Null/Favorite Menu
favorite page Delete Menu
fault page REVERSE/FORWARD Menu
Monitor Page REVERSE/FORWARD Menu
*Note: if Para ID2412 or Para ID2413 is set to hidden it
will hide this value.
1. In the main menu (root node), “JOG” shall be shown
on the right. If bypass is enabled, then “BYPASS” shall
be shown on the left. Otherwise, it will not be shown.
SeeFigure 10
Figure 11. Main menu
13:53BYPASS
JOG
STP FWD KEY TPM
S: Startup Wizard
M: Monitor
P: Parameter
