Johnson Controls VS3 Series User Manual

60 VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Chapter 6 — PID Application
Code Parameter Min. Max. Unit Default ID Note
M5.4 Application Status Word 29 Bit 0 = MC_Ready
Bit 1 = MC_Run
Bit 2 = MC_Fault or Fault Trip
Bit 3 = FB_Ref_Active
Bit 4 = MC_Stopping
Bit 5 = MC_Reverse
Bit 6 = MC_Warning or AR
Bit 7 = MC_ZeroSpeed
Bit 8 = IO Control Indicator
Bit 9 = Panel Control Indicator
Bit 10 = Panel Fieldbus Control Indicator
Bit 11 = MC_DC_Brake
Bit 12 = RunEnable
Bit 13 = Run Bypass
Bit 14 = External Brake Control
Bit 15 = In Bypass Mode
M5.5 Standard Status Word 2414 Bit 0 = See PAR ID 2415( default =
Ready )
Bit 1 = See PAR ID 2416( default = Run )
Bit 2 = See PAR ID 2417( default = Fault )
Bit 3 = See PAR ID 2418( default = Fault
Invert )
Bit 4 = See PAR ID 2419( default =
Warning )
Bit 5 = See PAR ID 2420( default =
Reversed )
Bit 6 = See PAR ID 2421( default = At
Speed )
Bit 7 = See PAR ID 2422( default = Zero
Frequency )
Bit 8 - 15 = Not Used
Table 68. PID Monitor — M6
Code Parameter Min. Max. Unit Default ID Note
M6.1 PID1 Set Point Varies 16
M6.2 PID1 Feedback Varies 18
M6.3 PID1 Error Value Varies 20
M6.4 PID1 Output % 22
M6.5 PID1 Status 23 0 = Stopped
1 = Running
2 = Sleep Mode
M6.6 PID2 Set Point Varies 32
M6.7 PID2 Feedback Varies 34
M6.8 PID2 Error Value Varies 36
M6.9 PID2 Output % 38
M6.10 PID2 Status 39 See Par ID 23
Table 67. FB Monitor Menu — M5, continued
