41
Chapter 5—Basic application
VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Table 32. Digital Output — P3.1 continued
Code Parameter Min. Max. Unit Default ID Note
P3.1.2
RO1 Function 62 152 See Par ID 151
P3.1.3
RO1 On Delay 0.0 320.0 s 0.0 2112
P3.1.4
RO1 Off Delay 0.0 320.0 s 0.0 2113
P3.1.5
RO2 Function 2 153 See Par ID 151
P3.1.6
RO2 On Delay 0.0 320.0 s 0.0 2114
P3.1.7
RO2 Off Delay 0.0 320.0 s 0.0 2115
P3.1.8
RO3 Function 3 538 See Par ID 151
P3.1.9
RO3 On Delay 0.0 320.0 s 0.0 2116
P3.1.10
RO3 Off Delay 0.0 320.0 s 0.0 2117
P3.1.11
RO3 Reverse 0 2118 0 = No
1 = Yes
P3.1.12
Virtual RO1 Function 0 2463 See Par ID 151
P3.1.13
Virtual RO2 Function 0 2464 See Par ID 151
Table 33. Supervisions — P3.2
Code Parameter Min. Max. Unit Default ID Note
P3.2.1
Freq Limit 1 Supv 0 154 0 = No Limit
1 = Low Limit Superv
2 = High Limit Superv
P3.2.2
Freq Limit 1 Supv Val 0.00 See Par ID 102 Hz 0.00 155
P3.2.3
Freq Limit 1 Supv Hyst 0.10 1.00 Hz 0.10 2200
P3.2.4
Freq Limit 2 Supv 0 157 See Par ID 154
P3.2.5
Freq Limit 2 Supv Val 0.00 See Par ID 102 Hz 0.00 158
P3.2.6
Freq Limit 2 Supv Hyst 0.10 1.00 Hz 0.10 2201
P3.2.7
Torque Limit Supv 0 159 See Par ID 154
P3.2.8
Torque Limit Supv Val -1000.0 1000.0 % 100.0 160
P3.2.9
Torque Limit Supv Hyst 1.0 5.0 % 1.0 2202
P3.2.10
Ref Limit Supv 0 161 See Par ID 154
P3.2.11
Ref Limit Supv Val 0.00 See Par ID 102 Hz 0.00 162
P3.2.12
Ref Limit Supv Hyst 0.10 1.00 Hz 0.10 2203
P3.2.13
Temp Limit Supv 0 165 See Par ID 154
P3.2.14
Temp Limit Supv Val -10.0 75.0 C 40.0 166
P3.2.15
Temp Limit Supv Hyst 1.0 10.0 C 1.0 2204
P3.2.16
Power Limit Supv 0 167 See Par ID 154
P3.2.17
Power Limit Supv Val -200.0 200.0 % 0.0 168
P3.2.18
Power Limit Supv Hyst 0.1 10.0 % 0.1 2205
P3.2.19
AI Supv Select 0 170 0 = AI1
1 = AI2
P3.2.20
AI Limit Supv 0 171 See Par ID 154
P3.2.21
AI Limit Supv Val 0.00 100.00 % 0.00 172
P3.2.22
AI Supv Hyst 1.00 10.00 % 1.00 2198
P3.2.23
Motor Current 1 Supv 0 2189 See Par ID 154
P3.2.24
Motor Current 1 Supv Value 0.0 DriveNomCurrCT*2 A DriveNomCurrCT 2190
P3.2.25
Motor Current 1 Supv Hyst 0.1 1.0 A 0.1 2196
P3.2.26
Motor Current 2 Supv 0 2191 See Par ID 154
P3.2.27
Motor Current 2 Supv Value 0.0 DriveNomCurrCT*2 A DriveNomCurrCT 2192
P3.2.28
Motor Current 2 Supv Hyst 0.1 1.0 A 0.1 2197
Note:
Parameter value will be set to be default when changing macros.
