119VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Chapter 7—Advanced application parameter
Table 185. Setpoint 2 — P8.3.3
Code Parameter Min. Max. Unit Default ID Note
P8.3.3.1
PID2 Set Point 2 Source 2 1383 See Par ID 1374
P8.3.3.2
PID2 Set Point 2 Min -200.00 200.00 % 0.00 1384
P8.3.3.3
PID2 Set Point 2 Max -200.00 200.00 % 100.00 1385
P8.3.3.4
PID2 Set Point 2 Sleep Enable 0 1386 See Par ID 1346
P8.3.3.5
PID2 Set Point 2 Sleep Unit Sel 0 2399 See Par ID 2398
P8.3.3.6
PID2 Set Point 2 Sleep Level Varies 0.00 2456
P8.3.3.7
PID2 Set Point 2 Sleep Delay 0 3000 s 0 1388
P8.3.3.8
PID2 Set Point 2 WakeUp Level -99999.99 99999.99 Varies 0.00 1389
P8.3.3.9
PID2 Set Point 2 Boost -2.0 2.0 1.0 1391
P8.3.3.10
PID2 Set Point 2 Comp Enable 0 1416 See Par ID 1346
P8.3.3.11
PID2 Set Point 2 Comp Max -200.00 200.00 % 0.00 1417
P8.3.3.12 FB PID2 Set Point 2 See Par ID 1298 See Par ID 1300 Varies 2548
Feedback
Table 186. Basic — P8.4.1
Code Parameter Min. Max. Unit Default ID Note
P8.4.1.1
PID2 Feedback Func 0 1392 See Par ID 1330
P8.4.1.2
PID2 Feedback Gain -1000.0 1000.0 % 100.0 1393
Table 187. Feedback 1 — P8.4.2
Code Parameter Min. Max. Unit Default ID Note
P8.4.2.1
PID2 Feedback 1 Source 2 1394 0 = Not Used
1 = AI1
2 = AI2
3 = Slot A: AI1
4 = Slot B: AI1
5 = FB Process Data Input 1
6 = FB Process Data Input 2
7 = FB Process Data Input 3
8 = FB Process Data Input 4
9 = FB Process Data Input 5
10 = FB Process Data Input 6
11 = FB Process Data Input 7
12 = FB Process Data Input 8
13 = PT100 Temperture
14 = PID1 Output
15 = SlotA PT100 Temp Channel 1
16 = SlotA PT100 Temp Channel 2
17 = SlotA PT100 Temp Channel 3
18 = SlotB PT100 Temp Channel 1
19 = SlotB PT100 Temp Channel 2
20 = SlotB PT100 Temp Channel 3
21 = FB PID2 Feedback 1
22 = FB PID2 Feedback 2
P8.4.2.2
PID2 Feedback 1 Min -200.00 200.00 % 0.00 1395
P8.4.2.3
PID2 Feedback 1 Max -200.00 200.00 % 100.00 1396
P8.4.2.4 FB PID2 Feedback 1 % 2552
Table 188. Feedback 2 — P8.4.3
Code Parameter Min. Max. Unit Default ID Note
P8.4.3.1
PID2 Feedback 2 Source 0 1397 See Par ID 1394
P8.4.3.2
PID2 Feedback 2 Min -200.00 200.00 % 0.00 1398
P8.4.3.3
PID2 Feedback 2 Max -200.00 200.00 % 100.00 1399
P8.4.3.4 FB PID2 Feedback 2 % 2553
Note:
Parameter value can only be changed after the drive has stopped.
Parameter value will be set to be default when changing macros.
