Chapter 6 — PID Application
Code Parameter Min. Max. Unit Default ID Note
P3.2.33
PID1 Superv Enable 0 1346 0 = Disabled
1 = Enabled
P3.2.34
PID1 Superv Upper Limit See Par ID 1298 See Par ID 1300 Varies 0.00 1347
P3.2.35
PID1 Superv Lower Limit See Par ID 1298 See Par ID 1300 Varies 0.00 1349
P3.2.36
PID1 Superv Delay 0 3000 s 0 1351
P3.2.37
PID2 Superv Enable 0 1408 See Par ID 1346
P3.2.38
PID2 Superv Upper Limit See Par ID 1360 See Par ID 1362 Varies 0.00 1409
P3.2.39
PID2 Superv Lower Limit See Par ID 1360 See Par ID 1362 Varies 0.00 1411
P3.2.40
PID2 Superv Delay 0 3000 s 0 1413
Table 81. Analog Output 1 — P3.3
Code Parameter Min. Max. Unit Default ID Note
P3.3.1
AO1 Mode 0 227 See Par ID 222
P3.3.2
AO1 Function 1 146 0 = Not Used
1 = Output Frequency
2 = Freq Reference
3 = Motor Speed (0-Nom)
4 = Motor Current (0-Nom)
5 = Motor Torque (0-Nom)
6 = Motor Power (0-Nom)
7 = Motor Voltage (0-Nom)
8 = DC-Bus Voltage
9 = PID1 Setpoint
10 = PID1 Feedback 1
11 = PID1 Feedback 2
12 = PID1 Control Error Value
13 = PID1 Control Output
14 = PID2 Setpoint
15 = PID2 Feedback 1
16 = PID2 Feedback 2
17 = PID2 Control Error Value
18 = PID2 Control Output
19 = AI1
20 = AI2
21 = Output Freq (-2-+2N)
22 = Motor Torque (-2-+2N)
23 = Motor Power (-2-+2N)
24 = PT100 Temperature
25 = FB Process Data Input 1
26 = FB Process Data Input 2
27 = FB Process Data Input 3
28 = FB Process Data Input 4
29 = FB Process Data Input 5
30 = FB Process Data Input 6
31 = FB Process Data Input 7
32 = FB Process Data Input 8
33 = SlotA PT100 Temp Channel 1
34 = SlotA PT100 Temp Channel 2
35 = SlotA PT100 Temp Channel 3
36 = SlotB PT100 Temp Channel 1
37 = SlotB PT100 Temp Channel 2
38 = SlotB PT100 Temp Channel 3
39 = User Defined Output
40 = Motor Current (-2-+2N)
P3.3.3
AO1 Minimum 1 149 0 = 0V / 0 mA
1 = 2V / 4 mA
P3.3.4
AO1 Filter Time 0.00 10.00 s 1.00 147
P3.3.5
AO1 Scale 10 1000 % 100 150
P3.3.6
AO1 Inversion 0 148 See Par ID 181
P3.3.7
AO1 Offset -100.00 100.00 % 0.00 173
ote: N
Parameter value will be set to be default when changing macros.
Table 80. Supervisions — P3.2, continued
To Next Page
