Chapter 2—Keypad overview
Figure 6. Keypad and display
Programmable Soft Key 2
Auto Control Place Select
Move Cursor Right
Start /Hand Button
Stop/Off Button
Back/Reset Button
Increase Value
Scroll Menu Up
Programmable Soft Key 1
Decrease Value
Scroll Menu Down
Move Cursor Left
Enter Menu
Confirm Selection
Chapter 2—Keypad overview
The keypad is the interface between the drive and the user. It features an LCD display, 3 LED lights
and 11 buttons. With the control keypad, it is possible to control the speed of a motor, to supervise
the state of the equipment and to set the frequency converter’s parameters. See Figure 5.
