62 VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Chapter 6 — PID Application
Parameters
Table 73. Basic Parameters — P1
Code Parameter Min. Max. Unit Default ID Note
P1.1
Min Frequency 0.00 See Par ID 102 Hz 0.00 101
P1.2
Max Frequency See Par ID 101 400.00 Hz Varies 102
P1.3
Accel Time 1 0.1 3000.0 s 20.0 103
P1.4
Decel Time 1 0.1 3000.0 s 20.0 104
P1.5
Motor Nom Current DriveNomCurrCT*1/10 DriveNomCurrCT*2 A DriveNomCurrCT 486
P1.6
Motor Nom Speed 300 20000 rpm Varies 489
P1.7
Motor PF 0.30 1.00 0.85 490
P1.8
Motor Nom Voltage 180 690 V Varies 487
P1.9
Motor Nom Frequency 8.00 400.00 Hz Varies 488
P1.10
HOA Source 0 2465 0 = I/O Terminal/Keypad/Fieldbus
1 = Keypad
2 = IO Terminal
3 = Fieldbus
P1.11
Hand Control Place 0 1695 0 = Keypad
1 = I/O Terminal Start 1
2 = I/O Terminal Start 2
3 = Fieldbus
P1.12
Hand Reference 6 136 0 = AI1
1 = AI2
2 = Slot A: AI1
3 = Slot B: AI1
6 = Keypad
7 = Fieldbus Ref
9 = Max Frequency
10 = AI1 + AI2
11 = AI1 - AI2
12 = AI2 - AI1
13 = AI1 * AI2
14 = AI1 or AI2
15 = MIN(AI1,AI2)
16 = MAX(AI1,AI2)
17 = PID1 Control Output
18 = PID2 Control Output
P1.13
Auto 1 Control Place 0 135 0 = I/O Terminal Start 1
1 = Fieldbus
2 = I/O Terminal Start 2
3 = Keypad
P1.14
Auto 1 Reference 1 137 See Par ID 136
P1.15
Auto 2 Control Place 1 138 See Par ID 135
P1.16
Auto 2 Reference 7 139 See Par ID 136
Inputs
Table 74. Basic Setting — P2.1
Code Parameter Min. Max. Unit Default ID Note
P2.1.1
Damper Start 0 483 0 = Normal
1 = Interlock Start
2 = Interlock Tout
3 = Interlock Delay
P2.1.2
Damper Time Out 1 32500 s 5 484
P2.1.3
Damper Delay 1 32500 s 5 485
P2.1.4
AI Ref Scale Min Value 0.00 See Par ID 145 Hz 0.00 144
P2.1.5
AI Ref Scale Max Value See Par ID 144 400.00 Hz 0.00 145
ote: N
Parameter value can only be changed after the drive has stopped.
Parameter value will be set to be default when changing macros.
