Chapter 5—Basic application
VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Table 48. FB Process Data Output Sel -- P12.2, continued
Code Parameter Min. Max. Unit Default ID Note
P12.2.9
Standard Status Word Bit0
Function Select
1 2415 27 = Ext Fault/Warning
28 = Auto Control
29 = Jog Speed Select
30 = Motor Therm Protection
31 = FB Digital Input 1
32 = FB Digital Input 2
33 = FB Digital Input 3
34 = FB Digital Input 4
36 = TC1 Status
37 = TC2 Status
38 = TC3 Status
40 = Power Limit Superv
41 = Temp Limit Superv
42 = Analog Input Superv
51 = Motor Current 1 Supv
52 = Motor Current 2 Supv
53 = Second AI Limit Supv
54 = DC Charge Switch Close
55 = Preheat Active
56 = Cold Weather Active
58 = 2th Stage Ramp Frequency
Active
59 = STO Fault Output
60 = Run Bypass/Drive
61 = Bypass Overload
62 = Bypass Run
P12.2.10
Standard Status Word Bit1 Function Select 2 2416 See Par ID 2415
P12.2.11
Standard Status Word Bit2 Function Select 3 2417 See Par ID 2415
P12.2.12
Standard Status Word Bit3 Function Select 4 2418 See Par ID 2415
P12.2.13
Standard Status Word Bit4 Function Select 5 2419 See Par ID 2415
P12.2.14
Standard Status Word Bit5 Function Select 6 2420 See Par ID 2415
P12.2.15
Standard Status Word Bit6 Function Select 7 2421 See Par ID 2415
P12.2.16
Standard Status Word Bit7 Function Select 8 2422 See Par ID 2415
RS485 Bus
Table 49. Basic Setting — P12.3.1
Code Parameter Min. Max. Unit Default ID Note
P12.3.1.1
RS485 Comm Set 0 586 0 = Modbus RTU
1 = BACnet MS/TP
2 = SA Bus
Table 50. Modbus RTU — P12.3.2
Code Parameter Min. Max. Unit Default ID Note
P12.3.2.1
Slave Address 1 247 1 587
P12.3.2.2
Baud Rate 1 584 0 = 9600
1 = 19200
2 = 38400
3 = 57600
4 = 115200
P12.3.2.3
Parity Type 2 585 0 = None
1 = Odd
2 = Even
P12.3.2.4 Modbus RTU Protocol Status 588 0 = Initial
1 = Stopped
2 = Operational
3 = Faulted
P12.3.2.5 Comm Timeout Modbus RTU 0 60000 ms 10000 593
P12.3.2.6 Modbus RTU Fault Response 2516 0 = in Fieldbus Control
1 = in all Control
otes: N
Parameter value can only be changed after the drive has stopped.
Parameter value will be set to be default when changing macros.
