Chapter 6 — PID Application
Table 82. Analog Output 2 — P3.4
Code Parameter Min. Max. Unit Default ID Note
P3.4.1
AO2 Mode 0 228 See Par ID 222
P3.4.2
AO2 Function 4 229 See Par ID 146
P3.4.3
AO2 Minimum 1 232 See Par ID 149
P3.4.4
AO2 Filter Time 0.00 10.00 s 1.00 230
P3.4.5
AO2 Scale 10 1000 % 100 233
P3.4.6
AO2 Inversion 0 231 See Par ID 181
P3.4.7
AO2 Offset -100.00 100.00 % 0.00 234
Drive Control
Table 83. Basic Setting — P4.1
Code Parameter Min. Max. Unit Default ID Note
P4.1.1
Keypad Reference See Par ID 101 See Par ID 102 Hz 0.00 141
P4.1.2
Keypad Direction 0 116 0 = Forward
1 = Reverse
P4.1.3
Keypad Stop 1 114 0 = Enabled-Keypad Operation
1 = Always Enabled
P4.1.4
Hand Key Enable 0 1724 0 = Enabled
1 = Disabled
P4.1.5
Reverse Enable 1 1679 See Par ID 1346
P4.1.6 Change PhaseSequence
Motor
0 2515 0 = Change Disable
1 = Change Enable
P4.1.7
Power Up HOA Select 0 1685 0 = Hold Last
1 = Hand Control
2 = Auto control
3 = Off
P4.1.9
Run Delay Time 0 32500 s 0 2423
P4.1.10
Start Mode 0 252 0 = Ramp
1 = Flying Start
P4.1.11
Stop Mode 0 253 0 = Coasting
1 = Ramp
P4.1.12
Ramp 1 Shape 0.0 10.0 s 0.0 247
P4.1.13
Ramp 2 Shape 0.0 10.0 s 0.0 248
P4.1.14
Accel Time 2 0.1 3000.0 s 10.0 249
P4.1.15
Decel Time 2 0.1 3000.0 s 10.0 250
P4.1.16
Power Loss Function 0 267 See Par ID 1346
P4.1.17
Power Loss Time 0.3 5.0 s 2.0 268
P4.1.18
2nd Stage Ramp Frequency See Par ID 101 See Par ID 102 Hz 30.00 2444
ote: N
Parameter value can only be changed after the drive has stopped.
Parameter value will be set to be default when changing macros.
