75VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Chapter 6 — PID Application
Table 94. Monitor — P7.2
Code Parameter Min. Max. Unit Default ID Note
P7.2.1 FB PID1 Set Point 1 See Par ID 1298 See Par ID 1300 Varies 2542
P7.2.2 FB PID1 Set Point 2 See Par ID 1298 See Par ID 1300 Varies 2544
P7.2.3 FB PID1 Feedback 1 % 2550
P7.2.4 FB PID1 Feedback 2 % 2551
P7.2.5 FB PID1 Feedforward 1 % 2554
P7.2.6 FB PID1 Feedforward 2 % 2555
Setpoint
Table 95. Basic — P7.3.1
Code Parameter Min. Max. Unit Default ID Note
P7.3.1.1
PID1 Keypad Set Point 1 See Par ID 1298 See Par ID 1300 Varies 0.00 1307
P7.3.1.2
PID1 Keypad Set Point 2 See Par ID 1298 See Par ID 1300 Varies 0.00 1309
P7.3.1.3
PID1 Wake Up Action 0 2466 0 = Below Wake Up Level
1 = Above Wake Up Level
2 = Below Wake Up Level(PID ref.)
Wake up when below wakeup
level % set in Para ID 1318 or
1327 from PID Setpoint.
3 = Above Wake Up Level(PID ref.)
Wake up when above wakeup
level % set in Para ID 1318 or
1327 from PID Setpoint.
Table 96. Setpoint 1 — P7.3.2
Code Parameter Min. Max. Unit Default ID Note
P7.3.2.1
PID1 Set Point 1 Source 1 1312 0 = Not Used
1 = PID1 Keypad Set Point 1
2 = PID1 Keypad Set Point 2
3 = AI1
4 = AI2
5 = Slot A: AI1
6 = Slot B: AI1
7 = FB Process Data Input 1
8 = FB Process Data Input 2
9 = FB Process Data Input 3
10 = FB Process Data Input 4
11 = FB Process Data Input 5
12 = FB Process Data Input 6
13 = FB Process Data Input 7
14 = FB Process Data Input 8
15 = PID2 Output
16 = FB PID1 Set Point 1
17 = FB PID1 Set Point 2
P7.3.2.2
PID1 Set Point 1 Min -200.00 200.00 % 0.00 1313
P7.3.2.3
PID1 Set Point 1 Max -200.00 200.00 % 100.00 1314
P7.3.2.4
PID1 Set Point 1 Sleep Enable 0 1315 See Par ID 1346
P7.3.2.5
PID1 Set Point 1 Sleep
Unit Sel
0 2396 0 = Output Frequency
1 = Motor Speed
2 = Motor Current
3 = PID1 Feedback
P7.3.2.6
PID1 Set Point 1 Sleep Level Varies 0.00 2450
P7.3.2.7
PID1 Set Point 1 Sleep Delay 0 3000 s 0 1317
P7.3.2.8
PID1 Set Point 1 Wake Up
Level
-99999.99 99999.99 Varies 0.00 1318
ote: N
Parameter value can only be changed after the drive has stopped.
Parameter value will be set to be default when changing macros.
