Johnson Controls VS3 Series User Manual

25VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Chapter 3—Menu overview
Value edit
This topic shows the methods to edit value, and what
will happen to edit value when password is in use and
parameter lock is enabled.
We have three methods to edit value: edit by key press-hold,
edit bit by bit, edit click by click.
For details, please see Figure 26. For the editable
parameter, press “Right” key once to enter the read mode
(just read the value of this parameter), press “Right” key
again to enter the edit mode (user can modify the value
of this parameter), press “Right” key again to enter the
bit-by-bit edit mode.
User shall use Left/Right key to change the current editable
bit. When editing one number, it increases/decreases
circularly, for example, pressing Up key can change to
9from0.
Figure 27. Edit parameter value
STP FWD KEY PAR
P1.16
Auto 2 Reference
P1.1 - Min Frequency
P1.2
Max Frequency
STP FWD KEY
P1.1
0.00Hz
Min Frequency
STP FWD KEY PAR
0.00Hz
Left key
STP
FWD KEY
PAR
0.01Hz
Up key Down key
STP FWD KEY PAR
0.00Hz
Up key 9
times
STP
FWD KEY PAR
0.10Hz
Up key
STP FWD KEY PAR
0.01Hz
STP FWD KEY PAR
0.00Hz
Left key
PAR
Right key
twice
P1.1
Min Frequency
P1.1
Min Frequency
P1.1
Min Frequency
P1.1
Min Frequency
P1.1
Min Frequency
P1.1
Min Frequency
13:53BYPASS FAVORITE
13:53BYPASS FAVORITE
13:53BYPASS FAVORITE
13:53BYPASS REVERSE
13:53BYPASS FAVORITE
13:53BYPASS FAVORITE
13:53BYPASS FAVORITE
13:53BYPASS FAVORITE
