Chapter 6 — PID Application
Table 131. BACnet IP — P12.4.3
Code Parameter Min. Max. Unit Default ID Note
P12.4.3.1

BACnet IP UDP port number 47808 1733 47808 = BAC0
47809 = BAC1
47810 = BAC2
47811 = BAC3
47812 = BAC4
47813 = BAC5
47814 = BAC6
47815 = BAC7
47816 = BAC8
47817 = BAC9
47818 = BACA
47819 = BACB
47820 = BACC
47821 = BACD
47822 = BACE
47823 = BACF
P12.4.3.2

BACnet IP Foreign Device 0 1734 See Par ID 1346
P12.4.3.3

BACnet IP BBMD IP 0.0.0.0 1735
P12.4.3.4

BACnet IP BBMD Port 47808 1737 See Par ID 1733
P12.4.3.5

BACnet IP Registration Interval 0 65535 10 1738
P12.4.3.6

BACnet IP Comm Timeout 0 60000 0 1739
P12.4.3.7 BACnet IP Protocol Status 1740 See Par ID 599
P12.4.3.8

BACnet IP Fault Behavior 0 1741 See Par ID 2516
P12.4.3.9

BACnetIP Instance Number 0 4194302 Varies 1742
System
Table 132. Basic Setting — P13.1
Code Parameter Min. Max. Unit Default ID Note
P13.1.1 Language 0 340 0 = English
1 = ₼㠖
2 = Deutsch
P13.1.2

Application 142 0 = Basic
1 = PID
2 = Advanced
P13.1.3

Parameter Sets 619 0 = No
1 = Reload Defaults
2 = Reload Set 1
3 = Reload Set 2
4 = Store Set 1
5 = Store Set 2
6 = Reset
7 = Reload Defaults VM
P13.1.4 Up To Keypad 620 See Par ID 2118
P13.1.5

Down From Keypad 621 0 = No
1 = All Parameters
2 = All, No Motor
3 = App Parameters
ote: N

Parameter value can only be changed after the drive has stopped.

Parameter value will be set to be default when changing macros.
