23VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Chapter 3—Menu overview
3. P13.1.6 Parameters Comparison
After the operation, the number of different parameter
will be shown. Then press the right key; the first
different parameter shall be shown.
The parameter name shall be shown in the second line,
and the value which is from keypad/default/set1/set2
shall be shown in the third line, the current value shall
be shown in the fourth line.
If the user wants to modify the current value, user shall
be able to enter the edit mode by right key.
User shall be able to browse all the different parameters
by up/down key.
During this operation, “waiting…” shall  ash, which
means it is in process.
When it is  nished, “OK” shall be shown.
See Figure 24.
Figure 25. Parameters comparison
Parameter Name
Compared Value
(Keypad, Default, Set1, Set2)
Current Value in Drive
Right/OK twice
and Up Key
Right key
Allows changing
OK Key
Right Key
Up Key
Down Key
Down Key
BYPASS
FAVORITE
13:53
STP FWD KEY PAR
Parameter Comparison
P13.1.6
Compare with Keypad
13:53
STP FWD KEY PAR
Parameter Comparison
P13.1.6
Waiting...
13:53
STP FWD KEY PAR
Compare with Keypad
P13.1.6
5
13:53
STP FWD KEY PAR
Continous
Fan Control
Temperature
13:53
STP FWD KEY PAR
Continous
Fan Control
Temperature
13:53
STP FWD KEY PAR
Continous
Fan Control
Continous
13:53
STP FWD KEY PAR
2 min
Backlight Time
1 min
BYPASS
REVERSE
13:53
STP FWD KEY PAR
P13.1.6: Parameter Comparison
P13.1.5: Down From Keypad
P13.1.7: Password
