Chapter 1—Variable Speed Drives Series III overview
VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Catalog number system
Figure 4. Johnson Controls Series III VSD—catalog numbering system
VS3 – 010 – 4 – UL1 – 0
Basic Naming
VS3 = Drive
Bypass Option
0 = N/A
Input / Output Voltage
2 = 230 V (208–240 V, –15%, +10%)
4 = 400 V (380–500 V, –15%, +10%)
5 = 600 V (525–600 V, –15%, +10%)
Style
UL1 = Open Drive UL Type 1
UL2 = Open Drive UL Type 12
EP0 = Open Drive IP20 with EMC Filter
EP1 = Open Drive IP21 with EMC Filter
EP2 = Open Drive IP54 with EMC Filter
VS3 hp Rating
208–240 V 380–500 V 525–600 V
001 = 1.0 hp, 4.8 A, 0.75 kW 1D5 = 1.5 hp, 3.3 A, 1.1 kW 003 = 3 hp, 4.5 A, 2.2 kW
1D5 = 1.5 hp, 6.6 A, 1.1 kW 002 = 2.0 hp, 4.3 A, 1.5 kW 005 = 5.0 hp, 7.5 A, 3.7 kW
002 = 2.0 hp, 7.8 A, 1.5 kW 003 = 3.0 hp, 5.6, 2.2 kW 7D5 = 7.5 hp, 10 A, 5.5 kW
003 = 3.0 hp, 11 A, 2.2 kW 004 = 4.0 hp, 7.6 A, 3 kW 010 = 10 hp, 13.5 A, 7.5 kW
004 = 4 hp, 12.5 A, 3.0 kW 005 = 5 hp, 9 A, 4 kW 015 = 15 hp, 18 A, 11 kW
005 = 5.0 hp, 17.5 A, 3.7 kW 7D5 = 7.5 hp, 12 A, 5.5 kW 020 = 20 hp, 22 A, 15 kW
7D5 = 7.5 hp, 25 A, 5.5 kW 010 = 10 hp, 16 A, 7.5 kW 025 = 25 hp, 27 A, 18.5 kW
010 = 10 hp, 31 A, 7.5 kW 015 = 15 hp, 23 A, 11 kW 030 = 30 hp, 34 A, 22 kW
015 = 15 hp, 48 A, 11 kW 020 = 20 hp, 31 A, 15 kW 040 = 40 hp, 41 A, 30 kW
020 = 20 hp, 61 A, 15 kW 025 = 25 hp, 38 A, 18.5 kW 050 = 50 hp, 52 A, 37 kW
025 = 25 hp, 75 A, 18.5 kW 030 = 30 hp, 46 A, 22 kW 060 = 60 hp, 62 A, 45 kW
030 = 30 hp, 88 A, 22 kW 040 = 40 hp, 61 A, 30 kW 075 = 75 hp, 80 A, 55 kW
040 = 40 hp, 114A , 30 kW 050 = 50 hp, 72 A, 37 kW 100 = 100 hp, 100 A, 75 kW
050 = 50 hp, 143 A, 37 kW 060 = 60 hp, 87 A, 45 kW 125 = 125 hp, 125 A, 90 kW
060 = 60 hp, 170 A, 45 kW 075 = 75 hp, 105 A, 55 kW 150 = 150 hp, 144 A, 110 kW
075 = 75 hp, 211 A, 55 kW 100 = 100 hp, 140 A, 75 kW 200 = 200 hp, 208 A, 132 kW
100 = 100 hp, 261 A, 75 kW 125 = 125 hp, 170 A, 90 kW 250 = 250 hp, 250 A, 160 kW
125 = 125 hp, 312 A, 90 kW 150 = 150 hp, 205 A, 110 kW
200 = 200 hp, 261 A, 132 kW
250 = 250 hp, 310 A, 160 kW
