99VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Chapter 7—Advanced application parameter
Table 145. Timer/Interval Control — M7
Code Parameter Min. Max. Unit Default ID Note
M7.1 TC1, TC2, TC3 558
M7.2 Interval 1 559 0 = Inactive
1 = Active
M7.3 Interval 2 560 See Par ID 559
M7.4 Interval 3 561 See Par ID 559
M7.5 Interval 4 562 See Par ID 559
M7.6 Interval 5 563 See Par ID 559
M7.7 Timer 1 s 0 569
M7.8 Timer 2 s 0 571
M7.9 Timer 3 s 0 573
Table 146. User Defined Output — M8
Code Parameter Min. Max. Unit Default ID Note
M8.1 Output Varies 2445
M8.2 Reference Varies 2447
Table 147. MWH Monitor — M9
Code Parameter Min. Max. Unit Default ID Note
M9.1 Total MWh Count Mwh 601
M9.2 Total Power Day Count 603
M9.3 Total Power Hr Count 606
M9.4 Trip MWh Count Mwh 604
M9.5 Trip Power Day Count 636
M9.6 Trip Power Hr Count 637
Table 148. Multi-Monitoring — M10
Code Parameter Min. Max. Unit Default ID Note
M10.1 Multi-Monitoring 1, 2, 3 30
Parameters
Table 149. Basic Parameters — P1
Code Parameter Min. Max. Unit Default ID Note
P1.1
Min Frequency 0.00 See Par ID 102 Hz 0.00 101
P1.2
Max Frequency See Par ID 101 400.00 Hz Varies 102
P1.3
Accel Time 1 0.1 3000.0 s 20.0 103
P1.4
Decel Time 1 0.1 3000.0 s 20.0 104
P1.5
Motor Nom Current DriveNomCurrCT*1/10 DriveNomCurrCT*2 A DriveNomCurrCT 486
P1.6
Motor Nom Speed 300 20000 rpm Varies 489
P1.7
Motor PF 0.30 1.00 0.85 490
P1.8
Motor Nom Voltage 180 690 V Varies 487
P1.9
Motor Nom Frequency 8.00 400.00 Hz Varies 488
P1.10
HOA Source 0 2465 0 = I/O Terminal/
Keypad/Fieldbus
1 = Keypad
2 = IO Terminal
3 = Fieldbus
Note:
Parameter value can only be changed after the drive has stopped.
Parameter value will be set to be default when changing macros.
