112 VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Chapter 7—Advanced application parameter
Table 166. Motor — P6.1, continued
Code Parameter Min. Max. Unit Default ID Note
P6.1.19
Preheat Enter Temp 0.0 19.9 ºC 10.0 2161
P6.1.20
Preheat Quit Temp 20.0 40.0 ºC 20.0 2162
P6.1.21
Preheat Output Volt 0.0 20.0 % 2.0 2163
Table 167. Drive — P6.2
Code Parameter Min. Max. Unit Default ID Note
P6.2.1
Line Start Lockout 2 750 0 = Disabled, No Change
1 = Enable, No Change
2 = Disabled, Changed
3 = Enable, Changed
P6.2.2
Fault Reset Start 0 2483 0 = Start/Stop After Fault Reset
1 = Restart After Fault Reset
P6.2.3
4mA Input Fault 0 306 0 = No Action
1 = Warning
2 = Warning: Previous Freq
3 = Warning: Preset Freq
4 = Fault
5 = Fault, Coast
P6.2.4
4mA Fault Frequency 0.00 See Par ID 102 Hz 0.00 331
P6.2.5
External Fault 2 307 See Par ID 308
P6.2.6
Input Phase Fault 2 332 See Par ID 308
P6.2.7
Uvolt Fault Response 2 330 See Par ID 308
P6.2.8
Unit Under Temp Prot 2 1564 See Par ID 308
P6.2.9
RTC Fault 1 955 See Par ID 308
P6.2.10
Replace Battery Fault
Response
1 1256 See Par ID 308
P6.2.11
Replace Fan Fault Response 1 1257 See Par ID 308
P6.2.12
Cold Weather Mode 0 2126 See Par ID 1346
P6.2.13
Cold Weather Volt. Level 0.0 20.0 % 2.0 2127
P6.2.14
Cold Weather Time Out 0 10 min 3 2128
P6.2.15 Cold Weather Password 2129
P6.2.16 Under Temp Fault Override 2130 See Par ID 2118
P6.2.17
STO Fault Response 2 2427 0 = No Action
1 = Warning
2 = Fault
Table 168. Communication — P6.3
Code Parameter Min. Max. Unit Default ID Note
P6.3.1
Fieldbus Fault Response 2 334 0 = No Action
1 = Warning
2 = Fault
3 = Fault, Coast
4 = Warning, Coast
P6.3.2
OPTCard Fault Response 2 335 See Par ID 308
P6.3.3
IP Address Confliction Resp 1 1678 See Par ID 308
P6.3.4
Keypad Comm Fault
Response
2 2157 See Par ID 308
Table 169. Auto Restart — P6.4
Code Parameter Min. Max. Unit Default ID Note
P6.4.1
AR Wait Time 1.00 300.00 s 1.00 321
P6.4.2
AR Trail Time 0.00 600.00 s 30.00 322
P6.4.3
AR Start Function 0 323 0 = Flying Start
1 = Ramp
Note:
Parameter value can only be changed after the drive has stopped.
Parameter value will be set to be default when changing macros.
