70 VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Chapter 6 — PID Application
Table 84. Brake — P4.2
Code Parameter Min. Max. Unit Default ID Note
P4.2.1
DC-Brake Current DriveNomCurrCT*15/100 DriveNomCurrCT*15/10 A DriveNomCurrCT*1/2 254
P4.2.2
Start DC-Brake Time 0.00 600.00 s 0.00 263
P4.2.3
Stop DC-Brake Frequency 0.10 10.00 Hz 1.50 262
P4.2.4
Stop DC-Brake Time 0.00 600.00 s 0.00 255
P4.2.5
Brake Chopper Define 0 251 0 = Disabled
1 = B(Run) T(Rdy)
2 = External
3 = B(Rdy) T(Rdy)
4 = B(Run) T(No)
P4.2.6
Flux Brake 0 266 0 = Off
1 = On
P4.2.7
Flux Brake Current ActiveMotorNomCurr*1/10 See Par ID 107 A ActiveMotorNomCurr*1/2 265
Table 85. Skip Frequency — P4.3
Code Parameter Min. Max. Unit Default ID Note
P4.3.1
Skip Range Ramp Factor 0.1 10.0 1.0 264
P4.3.2
Skip F1 Low Limit 0.00 See Par ID 257 Hz 0.00 256
P4.3.3
Skip F1 High Limit See Par ID 256 400.00 Hz 0.00 257
P4.3.4
Skip F2 Low Limit 0.00 See Par ID 259 Hz 0.00 258
P4.3.5
Skip F2 High Limit See Par ID 258 400.00 Hz 0.00 259
P4.3.6
Skip F3 Low Limit 0.00 See Par ID 261 Hz 0.00 260
P4.3.7
Skip F3 High Limit See Par ID 260 400.00 Hz 0.00 261
Table 86. Energy Savings Calc — P4.4
Code Parameter Min. Max. Unit Default ID Note
P4.4.1
Currency 0 2122 0 = $
1 = £
2 = €
3 = ¥
4 = Rs
5 = R$
6 = Fr
7 = kr
P4.4.2
Energy Cost Varies 0.00 2123
P4.4.3
Data Type 0 2124 0 = Cumulative
1 = Daily Avg
2 = Weekly Avg
3 = Monthly Avg
4 = Yearly Avg
P4.4.4 Energy Savings Reset 2125 0 = Not Reset
1 = Reset
ote: N
Parameter value can only be changed after the drive has stopped.
Parameter value will be set to be default when changing macros.
