209
Appendix A—Description of parameters
VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Code Modbus ID Parameter Application RO/RW
M7.9 573 Timer 3 2,3 RO
Timer 3 value in seconds, value counts up to set timer value. See the RTC parameter group for defined
Timer value.
M8.1 2445 Output 1,2,3 RO
User defined output value that can be seen in a specific desired unit and scale factor based on the
output frequency. This value will be displayed in the format selected by parameter Para ID 2426 with a
scale value from parameter Para ID 2462 and 2427.
M8.2 2447 Reference 1,2,3 RO
User defined reference value that can be seen in the desired unit and scale factor based on the
frequency reference. This value will be displayed in the format selected by parameter Para ID 2426 with
a scale value from parameter Para ID 2462 and 2427.
M9.1 601 Total MWh Count 1,2,3 RO
Energy Consumption MWH Meter (not resettable)
M9.2 603 Total Power Day Count 1,2,3 RO
Total Time Power is on, Days count (not resettable)
M9.3 606 Total Power Hr Count 1,2,3 RO
Total time Power is on, Hr Count (not resettable)
M9.4 604 Trip MWh Count 1,2,3 RO
Entergy Consumption MWH Meter(resettable)
M9.5 636 Trip Power Day Count 1,2,3 RO
Total Time Power is On, Days count (resettable)
M9.6 637 Trip Power Hr Count 1,2,3 RO
Total time Power is on, Hr Count (resettable)
M10.1 30 Multi-Monitoring 1,2,3 RW
Displays any 3 monitoring values in a single screen. The values are selectable via the
keypad menu. by going to the Multi-Monitor page and seeing 3 lines of Monitoring values, Up and Down
keys can be used to select the row and then hitting the left arrow key will allow for editing the value
then by going up and down.
