45
Chapter 5—Basic application
VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Table 41. Motor — P6.1, continued
Code Parameter Min. Max. Unit Default ID Note
P6.1.6
Motor Thermal Time 1 200 min 12 312
P6.1.7
Stall Protection 0 313 See Par ID 308
P6.1.8
Stall Current Limit 0.1 ActiveMotorNomCurr*2 A ActiveMotorNomCurr*13/10
P6.1.9
Stall Time Limit 1.0 120.0 s 15.0
P6.1.10
Stall Frequency Limit 1.00 See Par ID 102 Hz 25.00
P6.1.11
Underload Protection 0
P6.1.12
Underload Fnom Torque 10.0 150.0 % 50.0
P6.1.13
Underload F0 Torque 5.0 150.0 % 10.0
P6.1.14
Underload Time Limit 2.00 600.00 s 20.00
P6.1.15
Thermistor Fault
Response
2
P6.1.16
PT100 Fault Response 2
P6.1.17
Preheat Mode 0
P6.1.18
Preheat Control Source 31 2160 0 = DigIN:NormallyOpen
1 = DigIN:NormallyClose
2 = DigIN: 1
3 = DigIN: 2
4 = DigIN: 3
5 = DigIN: 4
6 = DigIN: 5
7 = DigIN: 6
8 = DigIN: 7
9 = DigIN: 8
10 = DigIN: A: IO1: 1
11 = DigIN: A: IO1: 2
12 = DigIN: A: IO1: 3
13 = DigIN: A: IO5: 1
14 = DigIN: A: IO5: 2
15 = DigIN: A: IO5: 3
16 = DigIN: A: IO5: 4
17 = DigIN: A: IO5: 5
18 = DigIN: A: IO5: 6
19 = DigIN: B: IO1: 1
20 = DigIN: B: IO1: 2
21 = DigIN: B: IO1: 3
22 = DigIN: B: IO5: 1
23 = DigIN: B: IO5: 2
24 = DigIN: B: IO5: 3
25 = DigIN: B: IO5: 4
26 = DigIN: B: IO5: 5
27 = DigIN: B: IO5: 6
28 = Time Channel 1
29 = Time Channel 2
30 = Time Channel 3
31 = Drive Temperature
32 = SlotA PT100 Temp
Channel 1
33 = SlotA PT100 Temp
Channel 2
34 = SlotA PT100 Temp
Channel 3
35 = SlotA Max PT100
Temp
36 = SlotB PT100 Temp
Channel 1
37 = SlotB PT100 Temp
Channel 2
38 = SlotB PT100 Temp
Channel 3
39 = SlotB Max PT100
Temp
40 = SlotA and SlotB Max
PT100 Temp
otes: N
Parameter value can only be changed after the drive has stopped.
Parameter value will be set to be default when changing macros.
